PARTS LIST FOR FPM-12, FPM-12/HF, FPM-24, FPM-115, FPM-220
REFERENCE NUMBER DESCRIPTION QUANTITY
1 Thread Forming Bolt M4 4
2 Cover (Strainer) 1
3 O-Ring 1
4 Strainer 1
5 Thread Forming Bolt M8 4
6 Housing Cover 1
7 O-Ring 1
8 Gear 2
9 Key Gear 1
10 Shaft (Gear) 2
11 Housing (Machined) 1
12 Fitting (Bung) 1
13 Swivel Nut 1
14 Bung Adaptor 1
15 Seal (Metal Inserted) 1
16 O-Ring (Viton) 1
17 Bypass Valve 1
18 Spring (Bypass Valve) 1
19 Elbow 1
20 Thread Forming Bolt M6 9
21A Motor, 12V DC 1
21B Motor, 12V DC HF 1
21C Motor, 24V DC 1
21D Motor, 115V AC, 60 HZ 1
21E Motor, 220V AC, 50 HZ 1
22 Thread Forming Bolt M4 4
23 Electrical Cover (M/C) 1
24 Drive Screw U Type 4
25 Label 1
26 Electrical Housing (M/C) 1
27 On Off Toggle Switch 1
28 Bracket (Switch) 1
29 Screw (CAM) 2
30 Cam (Switch) 1
31 Thread Forming Bolt Screw M4 2
32 Shaft (Lever) 1
33 Switch Cover (M/C) 1
34 Thread Forming Bolt M6 4
35 Lever 1
36 Nylock Nut 1
37 Cover Nozzle 1
38 Lock 1
39 Rivet 1
HOSE, SUCTION TUBE, POWER CABLE & FUEL CONTROL NOZZLE ASSEMBLY
40 Suction Tube 1
41 Hose Assembly 1
42 Fuel Control Nozzle 1
43 Power Cable Assembly (Only for DC Pumps) 1
PUMP ASSEMBLY
