Specifications

 Power Requirements: 9-32Vdc, 0.2 Amp maximum

 Weight: 0.4 lbs

 Mounting Orientation: Any

 Antenna power is 5V up to 100mA

GPS Specifications:

 GPS Type: 12-channel GPS satellite receiver using GPS constellation and satellite-based

augmentation system (SBAS), such as WAAS, EGNOS, MSAS and GAGAN to the extent of

WAAS compatibility.

 Approvals: Certified by GRT Avionics to FAR 91.227 when used with a ADS-B out device in

the “Approved Devices” section. GPS sensor meets TSO-C199, Appendix 1, Section A1.2.6 and

FAR Section 91.227(c) for ADS-B out.

NMEA0183 Sentences Transmitted

$GPGGA

$GPGLL

$GPGSA

$GPGSV

$GPRMC

$GPVTG

$GPZDA

$RAIM (proprietary)

Serial Combiner Specifications:

 User configurable serial ports: 3

 Available buad rates: 110, 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200

 Available Serial Port Functions: All serial port functions available on the display unit can be

used through the combiner, as well as ADS-B specific GPS outputs.
