1307.2020 |
Design and function
Tree Runner Rigging Bollard 71-879, 71-877, 71-818
Fig. 3: Rigging Bollard 71-818
1 Load rope 4 Rope sliding bracket
2 Base plate 5 Deection tubes
3 Tension strap 6 Brake pipe
Function of the Rigging Bollard
Depending on the model, the rigging bollard is attached to a tree
trunk with one to three tension straps. The removed part of the tree is
lowered in a controlled manner on a rope wrapped around the brake
pipe of the rigging bollard. Depending on the weight of the load, the
number of windings of the rope must be adjusted.
Wearing parts
Wearing parts such as ropes and belts are excluded from warranty
claims.
› You can reorder them if necessary from your dealer.
EN
