Pos. Display Description
6
"Setpoint"
Shows the setpoint.
After unlocking CU 323, the setpoint will flash.
Proportional pressure control. "PPP" will be flashing for one second
followed by the current setpoint for four seconds. This function is only
available for E-pump systems.
The tank symbol appears in tank-filling mode with float switches.
or "Setpoint"
Alternates between the tank symbol and the setpoint in tank-filling mode
with analog input.
External stop: Indicates that the system has been stopped externally via
a digital input.
Indicates that the system has been set to "OFF".
Indicates that the system has been set from "OFF" to "On". "On" is only
shown for three seconds after which the setpoint is shown.
Indicates that the buttons on CU 323 have been locked automatically. To
unlock the buttons, press [RESET] and arrow up or [RESET] and arrow
down simultaneously.
Indicates that the system is remotely controlled.
Local: Appears if attempts to change the local settings are made while
the system is remotely controlled.
7
"Measured value" Shows the actual, measured value on the outlet side.
Proportional setpoint at zero flow, PPS [bar]. "PPS" is visible if you press
[RESET] for four seconds. After [RESET] has been released, you can
adjust "PPS" by means of the arrow up or arrow down buttons. If the
buttons are not activated for four seconds, the system returns to normal
operation. This function is only available for E-pump systems.
Appears in tank-filling mode with float switches.
Appears in case of a primary sensor fault.
or "Measured value"
Alternates between the actual, measured value on the outlet side and
"H.L" when a maximum outlet pressure or a level limit has been
exceeded.
