Product data sheet
Energy efficiency class
A+
Screen diagonal
108 cm/43 inch
Power consumption
Operation 53,1 W/100 W max.
Standby 0,30 W
Networked standby 2,90 W
Annual power consumption
78 kWh
Maximum resolution
1920 × 1080
Additional information
Operating voltage:
220 … 240 V
~
, 50 … 60 Hz
Screen (dm²)
50 dm²
RoHS limits
Pb (lead)/Hg (mercury)
Pb concentration complies with RoHS limits/
0 mg
Peak luminance ratio
65%
Audio output
2 × 20 W music power
2 × 10 W sine power + 10 W sine power of
the subwoofer
The subwoofer is optional and therefore not
available on all products.
Default satellites
20
LNB power supply
13/18 V, 14/19 V optional, maximum
500 mA
LNB switching signal
0/22 kHz 650 mV +/- 250 mVpp
DiSEqC
1.0-operation, 1.1-operation, 1.2-operation
Digital reception ranges
Satellite
Ku band: 10,700 MHz … 12,750 MHz
Modulation: DVBS QPSK, DVBS2 QPSK,
8 PSK
IF band: 950 MHz … 2150 MHz
Signal level: –25 dBm … –65 dBm
Cable
Overall band: 110 MHz … 862 MHz
Modulation: 16 QAM, 32 QAM,64 QAM,
128 QAM and 256 QAM
Symbol rate: 4.0 Msym/s … 7.2 Msym/s
Terrestrial (DVB-T)
VHF/UHF-Band, bandwidth 7 MHz and
8 MHz
FFT size: 2 k, 8 k
Modulation: 16 QAM, 64 QAM, QPSK
Guard interval: 1/4, 1/8, 1/16, 1/32
Terrestrial (DVB-T2)*
VHF/UHF-Band, bandwidth 7 MHz and
8 MHz
FFT size: 1 k, 2 k, 4 k, 8 k, 16 k, 32 k
Modulation: 16 QAM, 64 QAM,
256 QAM, QPSK
Guard interval: 1/4, 19/256, 1/8, 19/128,
1/16, 1/32, 1/128
* DVB-T2 is optional and therefore not
available on all products.
Analogue reception ranges
C02 … C80, special channels S01 … S41
Preset channels
TV/Radio 6000 (satellite – DVB-S),
1000 (cable – DVB-C)
or 99 (analogue)
1000 (terrestrial – DVB-T) or
99 (analogue)
6 AV, 2 USB
Supported media files
Image files: jpg/jpe, bmp, png
Music files: m4a, aac, mp3, wav
Video files: mov, xvid, mpg, mpe, vob,
dat, trp, ts, avi, mp4, mkv
Weight
approx. 9.6 kg
Dimensions
W × H × D 97 cm × 60,9 cm × 7,6 cm
GRUNDIG 43 GFB 6621
Technical changes and errors reserved.
