GRUNDIG Service Chassis LX IDTV (iX)
Ersatzteilliste
Spare Parts List
LP-CHASSISMODUL IX
CHASSISBOARD IX
TV
MATERIAL-NR. / PART NO.: 275991022100
ǵ
3 / 2008
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
d©
NUR FÜR INTERNEN GEBRAUCH
FOR INTERNAL USE ONLY
275991022100 LP-CHASSISMODUL IX CHASSISBOARD IX
D 200 759550968500 DIODE BAS40
D 300 759551098400 DIODE Z9.1V 1.5W
D 315 759530510400 DIODE BAV 99
D 316 759530510400 DIODE BAV 99
D 317 759530510400 DIODE BAV 99
D 326 759551309300 BZT55B8V2 Z-DIODE
D 327 759530510400 DIODE BAV 99
IC 201 759551283500 IC FSA3357K8X
IC 204 759551406000 IC-SMD MAX8576EUB+T UMAX10
IC 302 759551251600 IC-CHIP FAN1587AMX
IC 305 759551251600 IC-CHIP FAN1587AMX
IC 307 759551411000 IC-CHIP NCP1117STAT3G SOT-
IC 308 759551268200 IC-CHIP MAX810STRG SOT23 RE
IC 309 759551392500 IC MST96885ATLD-LF
IC 310 759551375600 IC-CHIP K4S641632K-UC60 TSO
IC 312 759551114100 IC M25P40
IC 313 759551268500 IC-CHIP 74HC4052D SO16
IC 314 759550969800 IC M24C02-MNST6T
IC 315 759551322700 IP4776CZ38 (HDMI ESD PROTEC
IC 316 759551050700 IC 24LC21A-I/SN-CMOS18K/2.5
IC 317 759551375700 IC-CHIP TDA9886TS/V4 (SSOP
IC 319 759551407700 IC-CHIP CD4053PWR
IC 321 759551394600 IC-CHIP TB2924AFG HSOP36(AU
IC 323 759551375900 IC HPA00156PWR (AUDIO DAC+H
L 308 759550451500 SPULE 10UH R0814
L 334 759550541900 SMD SPULE 1UH K0805
L 370 759550541900 SMD SPULE 1UH K0805
L 371 759550541900 SMD SPULE 1UH K0805
L 803 759550975200 SPULE 10 UH
L 805 759550975200 SPULE 10 UH
L 806 759550975200 SPULE 10 UH
Q 602 759550973400 TRANS 2N002
Q 603 759550973400 TRANS 2N002
Q 800 830100484800 SMD TRANS BC848B/ BC847B P
Q 801 830100484800 SMD TRANS BC848B/ BC847B P
Q 802 759550973400 TRANS 2N002
Q 803 759550973400 TRANS 2N002
Q 804 830100484800 SMD TRANS BC848B/ BC847B P
S 303 759551313100 VERBINDER 12 POL.
S 314 759551220800 STECKER 10P 2MM 89400-1010
S 315 759551411500 KOPFHOERERBUCHSE
S 321 759551313000 BUCHSE VGA B10B
S 326 759550922900 EURO AV BUCHSE
SAW 301 759550921100 FILTER OFW K9656M
SAW 302 759550458000 FILTER OFW K3958M
SP 900 759551406100 PCMCIA VERBINDER 1857246-1
T 201 759551411900 TRANS FDS6984AS SO8 MOSFET
T 314 759551407900 TRANS-CHIP STS3DPF20V DUAL
T 345 759550973400 TRANS 2N002
T 346 759551283600 TRANS. PMV60EN N-CHAN.30V(D
TU 303 759551406200 TUNER THOMSON DTT75407
U 607 759551406300 IC-CHIP LD1117DTTR(ADJUSTAB
U 608 759551411000 IC-CHIP NCP1117STAT3G SOT-
U 610 759551406300 IC-CHIP LD1117DTTR(ADJUSTAB
U 700 759551406400 IC-CHIP CXD1968 (QUAD.50M6
U 800 759551406500 IC-CHIP 74ALVC00D SO14
U 801 759551414700 IC-SMD EDD2516AETA-6B-E TSO
U 803 759551406700 IC-CHIP UPD61111GM-100-UEV-
U 804 759551406800 IC-CHIP ICS728MLFT 8-SOIC V
U 805 759551406900 IC-CHIP MAX809TEUR+T SOT-23
U 806 759551407000 IC-SMD PCA9536DP TSSOP8
U 807 720086707400 SW/IC AT24C64AN-10SU-2.7 SO
U 900 720086723200 SW/IC APP4.1_SW1.1.33 GRUN
U 901 759551407100 IC-CHIP 74LVT244APW TSSOP20
U 902 759551407100 IC-CHIP 74LVT244APW TSSOP20
U 903 759551283000 IC-CHIP 74LVT245PW TSSOP20
U 904 759551407100 IC-CHIP 74LVT244APW TSSOP20
U 905 759551407100 IC-CHIP 74LVT244APW TSSOP20
U 906 759551407200 IC-CHIP 74LVC257APW TSSOP16
U 907 759551407100 IC-CHIP 74LVT244APW TSSOP20
U 908 759551407200 IC-CHIP 74LVC257APW TSSOP16
U 909 759551407200 IC-CHIP 74LVC257APW TSSOP16
U 910 759551407300 TRANS-CHIP PBLS4003D SOT457
X 301 759880544700 QUARZ 14.31818 MHZ
X 302 759551376200 QUARZ-CHIP 4MHZ SMXA120E HC
X 700 759551407400 QUARZ 20.48MHZ 20/20PPM CL=
X 800 759551407500 QUARZ 13.5MHZ 15PPM 18PF HC
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
( ! )
!
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Num-
mer 720108000001, sowie zusätzlich die eventuell ab-
weichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
as provided by the "Safety" Service Manual, part
number 720108000001, as well as the respective
national deviations.
Ersatzteilliste
Spare Parts List
LP-CHASSISMODUL IX
CHASSISBOARD IX
TV
MATERIAL-NR. / PART NO.: 275991022600
ǵ
3 / 2008
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
d©
NUR FÜR INTERNEN GEBRAUCH
FOR INTERNAL USE ONLY
275991022600 LP-CHASSISMODUL IX CHASSISBOARD IX
D 300 759551098400 DIODE Z9.1V 1.5W
D 315 759530510400 DIODE BAV 99
D 316 759530510400 DIODE BAV 99
D 317 759530510400 DIODE BAV 99
D 326 759551309300 BZT55B8V2 Z-DIODE
D 327 759530510400 DIODE BAV 99
IC 201 759551283500 IC FSA3357K8X
IC 302 759551251600 IC-CHIP FAN1587AMX
IC 305 759551251600 IC-CHIP FAN1587AMX
IC 306 720086723300 SW/IC EUG.LX_06_T00_G2_V3.2
IC 307 759551411000 IC-CHIP NCP1117STAT3G SOT-
IC 308 759551268200 IC-CHIP MAX810STRG SOT23 RE
IC 309 759551414800 IC-SMD MST96885ATL-LF LQFP2
IC 310 759551375600 IC-CHIP K4S641632K-UC60 TSO
IC 312 759551114100 IC M25P40
IC 316 759551050700 IC 24LC21A-I/SN-CMOS18K/2.5
IC 317 759551375700 IC-CHIP TDA9886TS/V4 (SSOP
IC 319 759551407700 IC-CHIP CD4053PWR
IC 321 759551394600 IC-CHIP TB2924AFG HSOP36(AU
IC 323 759551375900 IC HPA00156PWR (AUDIO DAC+H
L 334 759550541900 SMD SPULE 1UH K0805
L 370 759550541900 SMD SPULE 1UH K0805
L 371 759550541900 SMD SPULE 1UH K0805
L 803 759550975200 SPULE 10 UH
L 805 759550975200 SPULE 10 UH
L 806 759550975200 SPULE 10 UH
Q 602 759550973400 TRANS 2N002
Q 603 759550973400 TRANS 2N002
Q 800 830100484800 SMD TRANS BC848B/ BC847B P
Q 801 830100484800 SMD TRANS BC848B/ BC847B P
Q 802 759550973400 TRANS 2N002
Q 803 759550973400 TRANS 2N002
Q 804 830100484800 SMD TRANS BC848B/ BC847B P
S 315 759551411500 KOPFHOERERBUCHSE
S 321 759551313000 BUCHSE VGA B10B
S 326 759550922900 EURO AV BUCHSE
SAW 301 759550921100 FILTER OFW K9656M
SAW 302 759550458000 FILTER OFW K3958M
SP 900 759551406100 PCMCIA VERBINDER 1857246-1
T 314 759551407900 TRANS-CHIP STS3DPF20V DUAL
T 346 759551283600 TRANS. PMV60EN N-CHAN.30V(D
TU 303 759551406200 TUNER THOMSON DTT75407
U 607 759551406300 IC-CHIP LD1117DTTR(ADJUSTAB
U 608 759551411000 IC-CHIP NCP1117STAT3G SOT-
U 610 759551406300 IC-CHIP LD1117DTTR(ADJUSTAB
U 700 759551406400 IC-CHIP CXD1968 (QUAD.50M6
U 800 759551406500 IC-CHIP 74ALVC00D SO14
U 801 759551414700 IC-SMD EDD2516AETA-6B-E TSO
U 803 759551406700 IC-CHIP UPD61111GM-100-UEV-
U 804 759551406800 IC-CHIP ICS728MLFT 8-SOIC V
U 805 759551406900 IC-CHIP MAX809TEUR+T SOT-23
U 806 759551407000 IC-SMD PCA9536DP TSSOP8
U 807 720086707400 SW/IC AT24C64AN-10SU-2.7 SO
U 900 720086723200 SW/IC APP4.1_SW1.1.33 GRUN
U 901 759551407100 IC-CHIP 74LVT244APW TSSOP20
U 902 759551407100 IC-CHIP 74LVT244APW TSSOP20
U 903 759551283000 IC-CHIP 74LVT245PW TSSOP20
U 904 759551407100 IC-CHIP 74LVT244APW TSSOP20
U 905 759551407100 IC-CHIP 74LVT244APW TSSOP20
U 906 759551407200 IC-CHIP 74LVC257APW TSSOP16
U 907 759551407100 IC-CHIP 74LVT244APW TSSOP20
U 908 759551407200 IC-CHIP 74LVC257APW TSSOP16
U 909 759551407200 IC-CHIP 74LVC257APW TSSOP16
U 910 759551407300 TRANS-CHIP PBLS4003D SOT457
X 301 759880544700 QUARZ 14.31818 MHZ
X 302 759551376200 QUARZ-CHIP 4MHZ SMXA120E HC
X 700 759551407400 QUARZ 20.48MHZ 20/20PPM CL=
X 800 759551407500 QUARZ 13.5MHZ 15PPM 18PF HC
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
( ! )
!
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Num-
mer 720108000001, sowie zusätzlich die eventuell ab-
weichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
as provided by the "Safety" Service Manual, part
number 720108000001, as well as the respective
national deviations.
