GRUNDIG Service Chassis LX IDTV (iX)
Ersatzteilliste
Spare Parts List
LP-NETZTEILMODUL SMPS 32 LX (TSW)
POWER SUPPLY BOARD 32 LX (TSW)
TV
MATERIAL-NR. / PART NO.: 275990303100
ǵ
9 / 2007
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
d©
NUR FÜR INTERNEN GEBRAUCH
FOR INTERNAL USE ONLY
275990303100 LP-NETZTEILMODUL SMPS 32 LX (TSW) POWER SUPPLY BOARD 32 LX (TSW)
C 900
S 759551338200 470 NF K 305V-AC R:15 KONDE
C 905
S 759551338200 470 NF K 305V-AC R:15 KONDE
C 906
S 759551338300 1 NF M 250VAC Y5U R:10 KOND
C 907
S 759551338300 1 NF M 250VAC Y5U R:10 KOND
C 946
S 759550965300 KONDENS 220PF M 250VAC R:10
C 954
S 759880450800 KONDENS. 2.2NF 20% 250V
C 955
S 759880450800 KONDENS. 2.2NF 20% 250V
FS 900
S 759550935300 SICHERUNG T5 A / 250 V
IC 900 759551153100 IC ICE1QS01
IC 901 759551153100 IC ICE1QS01
IC 902 830544043100 IC TL431CLPRP MOT AV330 ER-
IC 903 830544043100 IC TL431CLPRP MOT AV330 ER-
L 900
S 759551309000 2X28MH 3A LINE FILTER
L 907
S 759550922500 COIL 40MH DTH30403H57
PH 900
S 759550963200 OPTOKOPPLER TCET 1100/V310
PH 901
S 759550963200 OPTOKOPPLER TCET 1100/V310
R 900
S 759550932300 ESTR. S14K385
R 901
S 759551353500 WIDERST. RM 480K 5W 52MM
R 923
S 759550452600 WIDERST 4,7MOHM1/2W
T 900 759551353800 TRANS. SPP11N60C3 0.38R 600
T 901 759551089900 TRANS 2SK3562 TO220FP
T 902 830100484800 SMD TRANS BC848B/ BC847B P
T 903 830100484800 SMD TRANS BC848B/ BC847B P
T 904 830100484800 SMD TRANS BC848B/ BC847B P
U 900
S 759551376300 TRAFO SMT JEWEL CODE BCK-32
U 901
S 759551353600 TRAFO SMT PULSE CODE 2722.9
ZD 900 759551244700 Z-DIODE 1N4746 18V
ZD 902 759551168600 DIODE-CHIP BZX384-C8V2 300M
ZD 903 759551244700 Z-DIODE 1N4746 18V
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
( ! )
!
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Num-
mer 720108000001, sowie zusätzlich die eventuell ab-
weichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
as provided by the "Safety" Service Manual, part
number 720108000001, as well as the respective
national deviations.
Ersatzteilliste
Spare Parts List
LP-NETZTEILMODUL LX 24/6 12/4 (ACT.PFC)
POWER SUPPLY BOARD LX 24/6 12/4 (ACT.PFC)
TV
MATERIAL-NR. / PART NO.: 275990303600
ǵ
12 / 2007
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
d©
NUR FÜR INTERNEN GEBRAUCH
FOR INTERNAL USE ONLY
S
275990303600 LP-NETZTEILMODUL LX 24/6 12/4 POWER SUPPLY BOARD LX 24/6 12/4
(ACT.PFC) (ACT.PFC)
C 2000
S 759550965300 KONDENS 220PF M 250VAC R:10
C 2001
S 759880450800 KONDENS. 2.2NF 20% 250V
C 2002
S 759551394900 CC 220PF K 2KV Y5P R:5
C 2003
S 759551338200 470 NF K 305V-AC R:15 KONDE
C 2004
S 759551338200 470 NF K 305V-AC R:15 KONDE
C 2005
S 759551338200 470 NF K 305V-AC R:15 KONDE
C 2006
S 759551394900 CC 220PF K 2KV Y5P R:5
C 2009
S 759550965300 KONDENS 220PF M 250VAC R:10
C 2010
S 759880450800 KONDENS. 2.2NF 20% 250V
C 2014
S 759551338300 1 NF M 250VAC Y5U R:10 KOND
D 2000 830953414900 MELF-DIODE LL 4148 TFK/ITT
D 2001 759551395000 DIODE 1N5406 600V 3A DO-201
D 2002 830953414900 MELF-DIODE LL 4148 TFK/ITT
D 2003 759551395100 DIODE MUR460 4A 600V ULTRAF
D 2004 830953414900 MELF-DIODE LL 4148 TFK/ITT
D 2005 830953414900 MELF-DIODE LL 4148 TFK/ITT
D 2006 830953414900 MELF-DIODE LL 4148 TFK/ITT
D 2007 830953414900 MELF-DIODE LL 4148 TFK/ITT
D 2008 759551395200 DIODE UF208G 2A 800V DO-15
D 2009 759551395300 DIODE UF4007F R:12.5
D 2010 759551395400 DIODE MBRF20200CT SCHT.20A
D 2011 759551395500 DIODE MBRF20100CT SCHT.20A
D 2013 830953414900 MELF-DIODE LL 4148 TFK/ITT
D 2014 830953414900 MELF-DIODE LL 4148 TFK/ITT
DB 2000 759551257100 BRUECKENDIODE 6A 600V KBU6J
FS 2000
S 759550921800 SICHERUNGSHALTER
IC 2000 759551395600 IC-CHIP NCP1606ADR2G SOIC-8
IC 2001 759551395700 IC NCP1207ADR2G SOIC-8
IC 2002 759551395700 IC NCP1207ADR2G SOIC-8
IC 2003 830544043100 IC TL431CLPRP MOT AV330 ER-
IC 2004 830544043100 IC TL431CLPRP MOT AV330 ER-
L 2000
S 759551395800 SPULE ACT.PFC 200UH 200W J
L 2001
S 759551396000 LINE FILTER 2X18MH 1.3A
L 2002
S 759551396000 LINE FILTER 2X18MH 1.3A
L 2003 759551395900 SPULE 4.7UH 3A RADIAL R:10
L 2004 759551395900 SPULE 4.7UH 3A RADIAL R:10
L 2005
S 759551396100 LINE FILTER DM LX 740UH 30%
PH 2000
S 759550963200 OPTOKOPPLER TCET 1100/V310
PH 2001
S 759550963200 OPTOKOPPLER TCET 1100/V310
R 2008
S 759550452600 WIDERST 4,7MOHM1/2W
R 2080
S 759551396200 RM 470K J 1/2W 52MM
T 2000 759551253700 TRANS. 2SK3568 500V 0.4 OHM
T 2001 759551396300 TRANS STP9NK70ZFP 700V 1R 7
T 2002 759551396400 TRN SPA08N80C3 800V 0.65R 8
T 2003 759551098700 TRANS BC848BLT1G
T 2004 759551098700 TRANS BC848BLT1G
T 2005 759551396500 TRANS MMBT2222ALT1 SO-G3/C2
T 2006 759551396500 TRANS MMBT2222ALT1 SO-G3/C2
U 2000 S 759551396600 TRAFO SMT BCK32050 LX 12V
U 2001
S 759551396700 TRAFO SMT BCK32048 LX 24V 3
VR 2001 759551396800 ESTR. EPCOS S14K320
ZD 2000 759551098500 DIODE 18 V 5 W
ZD 2001 759551098500 DIODE 18 V 5 W
ZD 2002 759551098500 DIODE 18 V 5 W
ZD 2005 759551309400 BZX55C3V3 Z-DIODE
ZD 2006 759551309400 BZX55C3V3 Z-DIODE
ZD 2007 759551309400 BZX55C3V3 Z-DIODE
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
( ! )
!
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Num-
mer 720108000001, sowie zusätzlich die eventuell ab-
weichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
as provided by the "Safety" Service Manual, part
number 720108000001, as well as the respective
national deviations.
