Grundig STR 110 microSAT - Technische Daten; Modulübersicht

STR 110 microSAT Allgemeiner Teil / General Section
GRUNDIG Service 1 - 3
Modulübersicht / Module List
Technische Daten
Programmspeicherplätze .......................................... 199 TV / Radio
Eingangsfrequenzbereich ........................................ 950…2150MHz
SAT-ZF-Eingang ............................................................................. 1
ZF-Bandbreite .................................... 4-Pegel Treshold Erweiterung
LNB-Power...................................................... 14 / 18V max. 350mA
DiSEqC .................................................................................. Simple
LNB-Schaltsignal .................................................................... 22kHz
LNB-Anpassung ..... 4 auswählbare LO-Frequenzen, 1MHz-Schritte
Ton-Frequenzbereich................................................. 5,0…9,00MHz
Stereo ..................................................................... Panda Wegener
Ton-Bandbreite ........................ 130 / 180 / 280 / 380 / 480 / 600kHz
Ton-Deemphasis umschaltbar .......................................... 50µs / J17
Videohub ............................ 16 / 22,5 / 25MHz / frei programmierbar
Videopolarität ............................................................positiv / negativ
LED-Anzeige ....... Betriebs- und Programmanzeige in der IR-Mouse
OSD-Menü ........................................................................... Englisch
Scartbuchsen .......................................................TV, VCR, Decoder
Netzspannung ................................................................. 220…240V
Regelbereich ................................................................... 190…264V
Netzfrequenz...................................................................... 50 / 60Hz
Fernbedienung ........................................ TP 720 SAT / TP 820 SAT
Abmessungen (BxHxT) ........................... ca. 116 x 218,5 x 48,5 mm
Gewicht ............................................................................. ca. 0,42kg
Leistungsaufnahme bei Vollast (mit LNC)............................ ca. 17W
Leistungsaufnahme in Standby.............................................. ca. 2W
Technical Data
Programme memory locations .................................. 199 TV / Radio
Input frequency range .............................................. 950…2150MHz
SAT IF-input .................................................................................... 1
IF bandwidth ..........................................4-Pegel Treshold extension
LNB power ..................................................... 14 / 18V, max. 350mA
DiSEqC .................................................................................. Simple
LNB switching signal ............................................................... 22kHz
LNB-Adaption...................... 4 variabel LI-Adjustments, 1MHz-steps
Sound frequency range.............................................. 5.0…9.00MHz
Stereo ..................................................................... Panda Wegener
Audio bandwidth ...................... 130 / 180 / 280 / 380 / 480 / 600kHz
Sound de-emphasis, switchable ....................................... 50µs / J17
Video deviation ....................16 / 22.5 / 25MHz / free programmable
Video polarity ........................................................positive / negative
Display LED ............... function- and program indication in IR mouse
OSD menu .............................................................................English
Scart sockets .......................................................TV, VCR, Decoder
Mains supply from external supply unit ........................... 220…240V
Control range of switched mode power supply ............... 190…265V
Mains frequency................................................................. 50 / 60Hz
Remote control handset .......................... TP 720 SAT / TP 820 SAT
Dimensions (WxHxD).............................. ca. 116 x 218.5 x 48.5 mm
Weight ............................................................................... ca. 0.42kg
Power consumption at full load (with LNC) .......................... ca. 17W
Power consumption in standby .............................................. ca. 2W
Chassis 29702-338.02
Tuner 29504-201.87
IR-Einheit 7-Seg., SAT-Maus
IR Unit 7-seg., SAT mouse
29636-140.01
Fernbedienung / Remote Control
TP 720 SAT / TP 820 SAT
29642-059.18 / 29642-061.03
