3. Specifications
PNEG-1456 1 and 2 Fan Vision Series Portable Dryers 15
1200 Series Dryer Specifications
1200S Series Dryer Specifications
1214 1216 1218 1220 1222 1226
Total Holding Capacity (Bushels) 381 436 490 544 599 708
Grain Column Holding
Capacity (Bushels)
329 376 423 470 517 611
Fan
26'' 10-13 HP
36'' 10-13 HP
26'' 10-13 HP
36'' 15 HP
26'' 10-13 HP
36'' 15 HP
28'' 10-13 HP
40" 15 HP
28'' 10-13 HP
42'' 20 HP
28'' 10-13 HP
42'' 25 HP
Top Auger
8'' Dia.
5 HP
8'' Dia.
5 HP
8'' Dia.
5 HP
8'' Dia.
7-1/2 HP
8'' Dia.
7-1/2 HP
8'' Dia.
10 HP
Capacity (BHP) 3800 3800 3800 3800 3800 3800
Bottom Auger
8'' Dia.
5 HP
8'' Dia.
5 HP
8'' Dia.
5 HP
8'' Dia.
7-1/2 HP
8'' Dia.
7-1/2 HP
8'' Dia.
10 HP
Meter Roll Drive SCR, 3/4 HP SCR, 3/4 HP SCR, 3/4 HP SCR, 3/4 HP SCR, 3/4 HP SCR, 3/4 HP
Capacity - MAXIMUM Rate
1
BHP)
1960 2240 2520 2800 3080 3640
Electrical Load (Fans, Top and Bottom Augers
2
)
1 Phase, 220 Volt 142 156 156 172 - -
3 Phase, 220 Volt 92 99 99 112 126 150
3 Phase, 440 Volt 47 50 50 57 63 75
3 Phase, 575 Volt 37 42 42 47 52 61
3 Phase, 380 Volt 50 61 61 70 75 90
1. Actual discharge rate is controlled by meter roll speed adjustment, at 5% to 100% of maximum rate.
2. Excludes auxiliary load and unload conveyor equipment.
1214S 1218S 1220S 1222S 1226S
Total Holding Capacity (Bushels) 381 490 544 599 708
Grain Column Holding Capacity (Bushels) 329 423 470 517 611
Fan
28'' 10-13 HP
(2)
36'' 10-13 HP
(2)
36'' 15 HP
(2)
36'' 15 HP
(2)
40'' 25 HP
(2)
Top Auger
8'' Dia.
5 HP
8'' Dia.
5 HP
8'' Dia.
7-1/2 HP
8'' Dia.
7-1/2 HP
8'' Dia.
10 HP
Capacity (BHP) 3800 3800 3800 3800 3800
Bottom Auger
8'' Dia.
5 HP
8'' Dia.
5 HP
8'' Dia.
7-1/2 HP
8'' Dia.
7-1/2 HP
8'' Dia.
10 HP
Meter Roll Drive SCR, 3/4 HP SCR, 3/4 HP SCR, 3/4 HP SCR, 3/4 HP SCR, 3/4 HP
Capacity - MAXIMUM Rate
1
(BHP)
1960 2520 2800 3080 3640
Electrical Load (Fans, Top and Bottom Augers
2
)
1 Phase, 220 Volt 142 142 186 186 -
3 Phase, 220 Volt 93 93 118 118 180
3 Phase, 440 Volt 47 47 60 60 90
3 Phase, 575 Volt 40 33 48 48 72
3 Phase, 380 Volt 50 50 80 80 115
1. Actual discharge rate is controlled by meter roll speed adjustment, at 5% to 100% of maximum rate.
2. Excludes auxiliary load and unload conveyor equipment.
