3. Installation
PNEG-1717 CE Approved GSI/FFI Portable Dryer Manual 11
Fuel
Liquid Propane (LP)
Liquid Draw
1. LPG is vaporized internally within the dryer.
2. LPG pipework and controls from the tank to the dryer must be installed by the gas supplier in
accordance with local directives, laws, codes and regulations.
3. LPG tank should be sized to supply the full heat input of all burners. See heater rating plates
for details.
Fuel System Specifications and Recommendations (LP) Liquid Propane
Dryer
Model #
Maximum Heat
Capacity kW
Maximum Fuel
Flow l/h
Fuel Line
Size mm *
Heater Orifice Diameter mm **
(U = Upper, L = Lower, Heater Position)
(T = Top, M = Middle, B = Base Dryer Module)
1108/190 880 131 15 7.8
1112/270 1320 195 15 9.6
1114/320 1685 250 15 10.9
1116/370 1685 250 15 10.9
1118/400 2052 302 15 12.0
1120/460 2200 326 15 12.4
1122/511 2491 370 22 13.2
1126/601 2785 414 22 13.9
1214/2120 1700 250 22 (U)8.8 (L)6.8
1216 1993 294 22 (U)10.2 (L)6.8
1218/2125 1993 292 22 (U)10.2 (L)6.8
1220/2130 2565 382 22 (U)10.7 (L)7.8
1222 2931 434 22 (U)11.7 (L)7.8
1226/2140 3078 458 22 (U)12.2 (L)7.8
1214S/2141 2052 302 22 (U+L) 8.8
1218S/2181 2638 390 22 (U+L) 10.3
1220S/500H 3371 501 22 (U+L) 10.7
1222S/2221 4104 609 22 (U+L) 11.7
1226S/650M 4397 653 22 (U+L) 12.2
2314/3142 3445 510 22 T 10.7 B (U+L) 7.8
2318/3182 4104 609 22 T 11.7 B (U+L) 8.8
2320/3202 4837 717 22 T 12.2 B (U+L) 10.2
2322/3222 5130 760 22 T 13.7 B (U+L) 10.2
2326/3262 7183 1063 22 T 14.2 B (U+L) 11.2
2420/1000H 5277 784 22 (T+B, U+L) 10.2
2426/1300M 7622 1130 22 (T+B, U+L) 11.2
3414/4143 5130 760 22 T 10.8 M 10.8 B (U+L) 7.8
3418/4183 6156 911 22 T 11.7 M 11.7 B (U+L) 8.8
3420/4203 7036 1043 22 T 12.2 M 12.2 B (U+L) 10.2
3422/4223 7622 1130 22 T 13.7 M 13.7 B (U+L) 8.3
3426/4263 9381 1389 22 T 14.2 M 14.2 B (U+L) 11.2
3620/1500H 7915 1174 22 (T+M+B, U+L) 10.2
3626/2000M 11433 1646 22 (T+M+B, U+L) 11.2
* Maximum line size for 30m length. ** Maximum burner pressure 450 mBar.
