GSi 61 - Page 76

Grason-Stadler GSI
®
61 CLINICAL AUDIOMETER
Function Function Group Function Sub Code Pushbutton/
Code Subgroup Function
01 Reserved for GSI 10
02 Channel 1 Stimulus “0” Tone
“1” NB Noise
“2” White Noise
“3” Speech Noise
“4” Mic
“5” Ext A
“6” Ext B
03 Reserved for GSI
10
04 Reserved for GSI
10
05 Channel 2 Stimulus “0” Tone
“1” NB Noise
“2” White Noise
“3” Speech Noise
“4” Mic
“5” Ext A
“6” Ext B
06 Transducer
Combinations Channel 1
Channel 2
“0” Bone Bone
“1” Spk Spk
“2” Spk Phone
“3” Bone Phone
“4” Phone Phone
“5” Phone Bone
“6” Phone Spk
“7” Phone Insert
“8” Bone Spk
“9” Bon
e Insert
“A” Spk Bone
“B” Spk Insert
“C” Insert Phone
“D” Insert Bone
“E” Insert Spk
“F” Insert Insert
07 Output Routing Channel 1
Channel 2
Combinations “0” Left Right
“1” Right Left
“2” Left Left
“3” Right Right
“4” Left/Right Left/Right
08 Subject Trigger “0” No
“1” Yes
09 F M “0” Off
“1” On
10 Interlock “0” Off
“1” On
11 Tracking “0” Off
“1” On
6-8
1761-0100 Rev. B
