Chapter 6 - Remote Options
Function Function Group Function Sub Code Pushbutton/
Code Subgroup Function
12
Reserved for GSI 10
13
Reserved for GSI 10
14
Reserved for GSI 10
15
Reserved for GSI 10
16
Test Frequency “0” Decrement Frequency
“1” Increment Frequency
17
Reserved for GSI 10
18
Channel 1 Tone Bar “0” Release
“1” Press
19
Channel 2 Tone Bar “0” Release
“1” Press
20
Channel 1 Intensity “0” Decrease 1 step
Control “1” Increase 1 step
21
Channel 2 Intensity “0” Decrease 1 step
Control “1” Increase 1 step
22
Channel 1 Interrupt “0” Off
“1” On
23
Channel 2 Interrupt “0” Off
“1” On
24
Reserved for GSI 10
25
Remote Output “0” Normal mode: Initiates
Request a data record transfer of the
current type selected on
the remote dip switches.
“1” HL Calibration Mode:
Stores the calibration
data into EEPROM.
All modes: Initiates a
data record transfer of
the current test type
selected on the remote
dip switches.
26
Pulsed “0” Off
“1” On
27
ALTernate “0” Off
“1” On
28
SISI “0” Off
“1” On
29
Transducer Type “0” Ch 1 Phone
“1” Ch 1 Bone
6-9
1761-0100 Rev. B
