Chapter 6 - Remote Options
Function Function Group Function Sub Code Pushbutton/
Code Subgroup Function
44
Transmit Unit “0”
configuration record
45
Load Default Data “0” Load HL configuration
default data
“1” Load Self Calibration
default data
“2” Load all default data
46
Perform Self-Cal “0”
47
Data Transfer Transmit a data output
record in the following
format:
“0” (Spare format, currently
defaults to “3”)
“1” GSI 16 Compatible
Short Data Record
“2” GSI 61 Short Data
Record
“3” Test Battery Data
Record
48
Enter Diagnostic “0” Exit to Normal Mode
Mode “1” Enter Push Button diagnostic
“2” Enter Display diagnostic
“3” Enter Hardware diagnostic
“4” Enter Loopback diagnostic
This record is used to set the frequency of the oscillator to the standard audiometric low
and high frequencies in the Normal, HL Calibration and SISI Calibration modes. This
record type is invalid in the Push Button diagnostic, Display diagnostic and Loopback
diagnostic modes. Nonstandard frequencies, frequencies outside the current range or
frequencies invalid for the current transducer are invalid and will result in an error record
being transmitted. Frequencies greater than 12 kHz are invalid if the GSI 16 compatible
record format is selected and will also result in an error record being transmitted.
Character Number of Field Name Field Description
Offset Characters
0
1
Record Prefix “:”
1
1
Record Type “6”
2
2
Function Code “01”
4
5
Test Frequency Format: Frequency value in Hz
( i.e. 750 Hz = “_750”)
Range: Low Freq. - 125 Hz to 12 kHz
High Freq. - 8 K to 20 kHz
Resolution: Standard Audio frequencies
9
2
Record “CR,” “LF”
Terminator
6-11
Input Record
Type 6- Set
Test
Frequency
Record
1761-0100 Rev. B
