GSi 61 - Page 80

The record which is set by this record varies based on the operating mode indicated
below. This record type is invalid in the Push Button Diagnostic, Display Diagnostic and
Loopback Diagnostic modes and will result in an error record being transmitted.
Character Number of Field Name Field Description
Offset Characters
0 1 Record Prefix “:”
1 1 Record Type “7”
2 2 Function Code “01” = Ch 1
“02” = Ch 2
4 4 HL value Format HL value with 1
implied decimal position
(i.e. 20 dB HL = “_200”)
Range:
Low Frequency: -10 to
120 dB HL
High Frequency: -20 to
100 dB HL
Resolution: 1 dB
8 2 Record Terminator “CR,” “LF”
Input Record
Type 7 - Set HL
Record
6-12
