GSi 61 - Output Record Types

These records are sent by the GSI 61 to the remote computer to transfer parameter or
status information. During the time that an output record is being sent and transmitted,
the Data Transfer indicator is displayed on the LCD panel. The indication displays for a
minimum of 0.5 seconds.
Character Number of Field Name Field Description
Offset Characters
0 1 Record Prefix “:”
1 1 Record Type “1”
2 1 Test Type “0” = Tone test
“1” =Speech test
“3” =SISI test
“4” =Alternate test
3 1 Ch 1 Stimulus “1” =Tone
“2” =NB Noise
“3” =White Noise
“4” =Speech Noise
“5” =Mic
“6” =Ext A
“7” =Ext B
4 1 Zero Field “0”
5 1 SISI “0” =None/Off
“1” =Reserved for GSI 10
“2” =On with 1 dB step size
“3” =On with 2 dB step size
