GSK 988T - Parameters Related to the Stroke Detection

Chapter Ⅺ Parameters
317
Ⅱ Operation
『Value Range』: -99 999 999～+99 999 999
This is one parameter to set the origin location of the work piece coordinate system (G54~G59). The
parameter is the valid common offset amount for all the work piece coordinate system.
SETTING UNIT IS-B IS-C UNIT
Linear axis (Metric input) 0.001 0.0001 mm
Linear axis (Inch input) 0.0001 0.00001 inch
Rotary axis 0.001 0.0001 deg
1240 Coordinate value of 1st Reference Position on each axis in the
machine coordinate system(RF1)
1241 Coordinate value of 2nd Reference Position on each axis in the
machine coordinate system(RF2)
1242
Coordinate value of 3rd Reference Position on each axis in the
machine coordinate system(RF3)
1243
Coordinate value of 4th Reference Position on each axis in the
machine coordinate system(RF4)
『Modification authority』: Equipment management authority
『Way of Validating』: 1240 valid after power on; 1241～1243 valid immediately.
『Parameter Type』: Word axis
『Value Range』: -99 999 999～+99 999 999
Set the coordinate values from the 1
st
to the 4
th
reference positions in the mechanical coordinate
system.
SETTING UNITS IS-B IS-C UNITS
Machine in metric system 0.001 0.0001 mm
Inch machine 0.0001 0.00001 inch
Rotary axis 0.001 0.0001 deg
1260 Amount of a shift per one rotation axis(PRA)
『Modification authority』: Equipment management authority
『Way of Validating』: After power-on
『Parameter Type』: Word axis
『Value Range』: 1000～9 999 999
Set the movement amount of each turn in rotary axis.
11.5 Parameters Related to the Stroke Detection
Setting unit of stroke parameter Nos.1320~1327 is shown in the following table:
Setting unit IS-B IS-C Unit
Metric machine 0.001 0.0001 mm
Inch machine 0.0001 0.00001 inch
