GSL MPPT60-1 - Panel Configuration Table

Page 8 of 8
Model:
MPPT60-1
Operating Instructions
Please read these instructions before use
Unit 2, 110 Station Road, Seven Hills ,NSW, 2147, Australia
1700W Solar Battery Charger
Maximum Power Point Tracker
MPPT60-1-R11
V
OC
V
MP
12V Charging 24V Charging
21 16
42 32
�
63 48
� �
84 64
� �
42 32
�
84 64
� �
Grid Connect Panel
(size
= no. cells in grid)
1x18 Cell Grid 10 8
1x48 Cell Grid 28 23
�
2x48 Cell Grid 56 46
� �
3x48 Cell Grid 84 69
� �
1x52 Cell Grid 31 25
�
2x52 Cell Grid 62 50
� �
1x54 Cell Grid 32 26
�
2x54 Cell Grid 64 52
� �
1x60 Cell Grid 36 29
�
2x60 Cell Grid 72 58
� �
1x72 Cell Grid 44 36
� �
1x96cgsp 65 55
� �
For optimal performance from panel and MPPT please use the following table to
determine the best setup for your situation.
