I-9102 Intelligent Photoelectric Smoke Detector
Installation and Operation Manual
The Intelligent Solution
Page 1
I General
I-9102 Intelligent Photoelectric Smoke Detector (hereinafter called the detector) is
designed on the principle of scattering of infrared beam. With novelty structure and
attractive appearance, the detector has stable and reliable performance and high ability
of damp-proof, applicable to hotels, restaurants, office buildings, teaching buildings,
banks, warehouses, libraries, computer rooms and switch rooms, etc.
II Features
1. The address code is written in by hand held programmer, making commission
simple and reliable.
2. Microprocessor can collect and process data in real time, and can store 14 history
records, displaying the field condition by curves.
3. Compensation for drift of temperature and humidity, and detection of dust
accumulation fault.
4. Remote output terminals connecting with remote LED.
5. Non-polarized two-bus.
III Technical Specifications
1. Operating Voltage: Loop 24V (16V～28V)
2. Operating Current:
Standby Current≤0.8mA
Alarm Current≤5.0mA
3. Operating Environment:
Temperature: -10℃～+50℃
Relative Humidity≤95%, non condensing
4. Monitoring Area: When the space height is 6m～12m, the monitoring area of a
detector is 80m
2
for normal protection area. When the space height is less than 6m,
it’s 60m
2
.
5. Alarm Confirming LED: Red, flashes normally, constantly lights when alarming.
6. Programming Mode: Electronic programming within 1~242.
7. Remote Output: Connecting with LED（5.1k Resistor in series is inside, output
voltage is 4.3V）
8. Dimension: Diameter: 100mm Height: 43mm（excluding the base）
9. Ingress Protection Rating: IP22
10. Material and Color of Enclosure: ABS, ivory white
11. Weight: About 120g
12. Mounting Hole Distance: 45mm~75mm
13. According to Standard: EN 54-7
