Replacement Parts
_
VIEW I
REF# 3
J
K
K
N
O
S
Q
E =
F =
I
2X 7 Nm
2X 8 Nm
4 Nm
4X 1 Nm
Unless otherwise specied, apply medium strength
(Loctite 242 (blue) removable thread locker 180 degrees
on all bolt threads.
Lightly grease all bearings before press t.
Lightly grease under all counter-sink bolt heads.
