25
Section 6 — Exploded Views and Parts Lists
Engine – Drawing No. 0G5598-E - Part 2
ITEM PART NO. QTY. DESCRIPTION
1 0C1069 9 SCREW HHTT M6-1.0 X 8 ZYC
2 0G5643 1 ASSEMBLY, BLOWER HOUSING
3 0E9521 1 PULLEY STARTER LARGE FRAME
4 0E9483 1 RECOIL STARTER LARGE FRAME
5 088434 1 WRAPPER, BOTTOM 12 HP HS
6 045756 10 SCREW HHTT M6-1.0 X 10 YELLOW
CHROME
7 0C4176A 1 WRAPPER, TOP REGULAR STEEL
8 0D9004A 1 ASSEMBLY, STARTER 46
9 059985 2 SCREW, SHC M8-1.25 X 45 G12.9
10 022129 2 WASHER, LOCK M8-5/16
11 073116A 1 BACKPLATE, W/ ELECTRIC START
12 083512 1 SCREW, HHTT M8-1.25 X 16 YELLOW
CHROME
13 0D7199A 1 HOSE, BREATHER GH410 ENGINES
14 091039 1 GASKET, INTAKE ADAPTER
15 036916 2 SCREW PPHM #8-32 X 1/4
16 087858N 1 ASSEMBLY, WIRE #0-4.5” LONG (NOT
SHOWN)
17 022097 2 WASHER, LOCK M6-1/4
18 0C4373 1 SPACER, ENDFRAME GH 410
19 086999 1 GASKET,OIL FILTER ADAPTER
20 0D5667 1 ADAPTER, OIL FILTER NO TAPPED HOLES
21 049821 2 SCREW, SHC M8-1.25 X 30 G12.9
22 0D9235 1 SWITCH, HOBBS OIL PRESSURE 5PSI
23 070185B 1 FILTER, OIL BLACK 75 LONG
24 082774 1 KEY, WOODRFF 4 X 19D
25 091222C 1 FLYWHEEL, WITH RING GEAR 27 DEGREE
26 067198N 1 WASHER,BELV-20 X 2.2
27 067890 1 NUT HEX M20-1.5 G8 YLW CHROME-
FLYWHEEL
28 0E7585 1 SPARKPLUG, CHAMPION RC14YC
29 072734 1 ASSEMBLY,GOVERNOR LEVER 12HP
30 072735 1 ROD, GOVERNOR CONTROL
31 0C3978 1 SPRING, ANTI-LASH
32 0G2386 1 ENGINE HARNESS, PORTABLE
33 0G9241 1 ASSEMBLY, IGNITION ADV NO DIODE
GH410
34 0G3111 2 SCREW, HHTT M6-1.0 X 25 ZINC
ITEM PART NO. QTY. DESCRIPTION
35 073100 1 SPRING GOVERNOR 320/360/410
36 083502 1 BOLT, GOVERNOR ADJUSTMENT M5
37 082025 1 NUT, HEX LOCK M5-0.8 NYLON INSERT
ZINC
38 081647 2 BOLT, CARBURETOR MOUNTING
40 040945 2 SCREW, SHC M6-1.0 X 20 G12.9 ZINC
PLATED
41 0A4600 1 CARBURETOR, 410HS
42 090970 1 GASKET, AIR CLEANER
43 0G5630A 1 BASE, AIR CLEANER 410 HI FLOW
44 049811 4 WASHER, FLAT M6
45 0B2236 2 NUT, HEX LOCK M6-1.0 NYLON INSERT
46 091204 1 PLATE, SPITBACK
47 059635 1 SCREW, PLASTITE #8 X .37 LONG
48 073111 1 ELEMENT, AIR FILTER
49 081646 1 PRECLEANER, AIR FILTER
50 079246 2 SCREW, HHC M6-1.0 X 16 W/ LOCK
WASHER
51 090827 1 BRACKET, AIR CLEANER
52 091028 1 ADAPTER, "K"
53 089228 1 GASKET, CARBURETOR/MANIFOLD
54 083504 1 KNOB, CHOKE LEVER
55 073104B 1 COVER, AIR CLEANER 13GN
56 078609 2 BOLT, AIR CLEANER COVER
57 0G5473 1 SWITCH, ENGINE RUN-STOP
58 0E5223A 1 MUFFLER, 410 SIDE-OUT ALUMINIZED
59 040976 2 SCREW, SHC M8-1.25 X 20 G12.9
60 090239 1 GASKET, EXHAUST
61 0F9176D 1 HOSE,1/4" SAE30R7 SETIFLEX 6"
62 048031C 1 CLAMP, HOSE BAND 1/2”
63 040173 1 CLAMP, HOSE WORM GEAR
64 073101 1 GOVERNOR BRKT.
65 082025 1 NUT HEX LOCK M5-0.8 NYINS ZINC
66 083512 3 SCREW, TAPTITE M8 X 15
67 066311 1 NUT, JAM M8-1.25
68 083502 1 SCREW, ADJUST
69 073100 1 SPRING, 60 Hz GOV.
70 083782 1 ASSEMBLY, IDLE COIL
71 0G2386 1 ENGINE HARNESS (NOT SHOWN)
