Guardian MDS86850EP User Manual

MDS86850E (PIC-00311)
Revised: 02/03/16
Rollator Parts List
Note: You may wish to request a set up and operating demonstration with your local
Medical
Equipmentproviderorpharmacy.
Assembled Rollator
A. Handgrips
B.
Adjustable Handlebars
C.
Star Knob
D.
Padded Backrest
E.
Backrest Push Buttons
F.
Padded Seat
G.
Brake Lock
H.
Brake Cables
I. Folding Support Bracket
J.6"(15.2cm)Front
Wheels
K.
6"(15.2cm)Back
Wheels
L.
Storage Bag
Figure2:StarKnob
C
3
Rollator Parts List
1RollatorFrame
1BackrestwithPush-buttons
2Handlebars
1bag
2Front
Wheels
2
Rear
Wheels
2
StarKnobs
2ScrewsandCurved
W
ashers
A
B
D
E
H
F
J
C
G
I
Figure1:AssembledRollator
K
Front
Back
L
