Guardian MDS86850ES - Rollator Parts List

MDS86850ES (PIC-00311)
Revised: 10/13/2017
Rollator Parts List
Note: You may wish to request a set up and operating demonstration with your local
Medical Equipment provider or pharmacy.
Figure 1: Assembled Rollator
Assembled Rollator
A. Handgrips
B. Adjustable Handlebars
C. 4 Point Knobs
D. Backrest Sling
E. Backrest Attachment
F. Seat
G. Brake Lock
H. Brake Cables
I. Folding Support Bracket
J. 6" (15.2 cm) Front Wheels
K. 6" (15.2 cm) Back Wheels
Figure 2: 4 Point Knob
C
3
1 Rollator Frame
1 Backrest Sling
2 Handlebars with Brake Assembly
1 Bag
2 Front Wheels
2 Rear Wheels
2 4 Point Knobs
2 Screws and Curved Washers
A
B
D
E
H
F
J
K
C
G
I
