Guardian WRT-20 - Figure 3 - Features WRT-20 with Optional Mounting Plate; Figure 4 - Overall Dimensions WRT-20 with Optional Mounting Plate

Guardian Telecom Inc.
Installation and Operation
Model WRT
FACEPLATE - 16 GA STEEL, SATIN
COAT PRIMED AND POWDER COATED
MEMBRANE KEYPAD (WRT-20)
ID & APPROVALS
WIRING ACCESS PLATE
Figure 3 - Features WRT-20 with Optional Mounting Plate
Page 6
Figure 4 - Overall Dimensions WRT-20 with Optional Mounting Plate
6.0" [152mm]
3.9" [99mm] 3.8" [97mm]
2.9" [74mm]
9.7" [246mm]
13.0" [330mm]
11.8" [300mm]
Ø0.3" [Ø7mm]
12.0" [305mm]
14.0" [356mm]
3.0" [75mm]
