5.3.3 Customizing Your 12v Relay Sengs
Delay Time Seng: C. 12v Relay Duraon
Switches 3 and 4 control how long your external 12v relay
device will stay acvated aer it has been triggered:
• 1 second - Switch 3 right, Switch 4 right
• 5 seconds - Switch 3 right, Switch 4 le
• 10 seconds - Switch 3 le, Switch 4 right
• 60 seconds - Switch 3 le, Switch 4 le
Output Terminal: External devices, such as gate openers,
door releases, or external speakers, can be wired to the
receiver using the 12V out relay. Reference the instrucons
that came with your 12v device to see how it should be
installed.
12V Out: This terminal outputs 12V/300mA when the
selected zone is triggered in cooperaon with “E” (12V
Output Control). Note: See secon “E” (12V Output Control)
below for assigning zones.
NO (Normally Open): Outputs to a closed circuit when
the selected zone is triggered in cooperaon with “F”.
See secon “F” (NO/NC Control) below for assigning zones.
COM: Neutral/Grounding terminal.
NC (Normally Closed): Outputs to an open circuit when
the selected zone is triggered. See secon “F” (NO/NC
Control) below for assigning zones.
The NO and NC outputs cooperate with “F” (NO/NC Control).
12V Output Control:
Selects which zone(s) will
trigger your 12v device that
is plugged into either the +
or - terminal. Switches 5-8
are linked to zones 1-4. For
example, engaging switch 5
will allow signals from zone
1 to trigger the aached 12v
device.
Switches 5-8 only aect 12v devices that are connected to
the + and - terminals. If your device is connected to the NO
or NC terminals, use switches 9-12.
NO/NC Control: Selects
which zone(s) will trigger
your 12v device that is
plugged into either the NO
or NC terminals. Switches
9-12 are linked to zones
1-4. For example, engaging
switch 9 will allow signals
from zone 1 to trigger the
aached 12v device.
NOTE
Switches 9-12 only aect 12v devices that are plugged into
either the NO or NC terminal.
