Please read carefully these Operating Instructions before putting the appliance into operation.
A.V. 2
Any reprints, even partial, are subject to approval. Technical changes reserved.
Identification:
Warnings/prohibitions:
Fill the pump with water.
Other persons must step
aside at a sufficient distance.
Oil low level sensor (see
user guide)
Throttle lever adjustment
General warning instructions
Use outdoors only, toxic flue
gases
Warning instructions for
refuelling
Check for oil level before
starting.
Product safety:
The product complies with
relevant EU standards
Environment protection:
Dispose waste not to harm
your environment.
Packaging material from
cardboard can be recycled
in a collection point.
Defective and/or disposed
electric or electronic devices
must be delivered to relevant
collection points.
Technical data:
Motor power Volume of cylinders
Delivered volume Suction lift
Total head Weight
Noise level Pressure connection
Device description (figure A/B)
1. Tank
2. Tank lid
3. Exhaust
4. Frame
5. Suction neck
6. Rubber foot
7. Oil level indicator
8. Oil draining screw
9. Oil low level sensor
10. ON/OFF switch
11. Bowden starter
12. Throttle lever
13. Filling neck
14. Output neck
15. Saturator
16. Air filter
17. Carburettor
18. Draining screw
19. Gasoline cock
Accessories (Fig. C)
1. 2 x hose connector
2. 3 x hose clamps
3. 1 x wrench for spark plugs
4. 1 x foot valve (strainer)
