Gude GSE 950 - Cleaning and Maintenance; Air Filter Maintenance; Fuel Filter Maintenance; Spark Plug Maintenance

Abb. F
Cleaning and Maintenance
For goog functioning and a long lifespan for the machine, regular cleaning and maintenance is essential.
Do not smoke during the below work. Do no work int the vicinity of sparks, flames or open fire
Air filter
The air filter should be cleaned after every 50 operating hours.
• Loosen the 4 screws (fig D/15).
• Remove the lid (fig D/16).
• Remove the air filter (fig D/17) from the lid.
• Clean the filter with spirits or ethanol.
• Sprinkle the filter with petrol.
• Pinch the filter out. Do not twist!
Fuel filter
• Remove the lid (fig E/11) from the filler opening.
• Lift fhe fuel filter (fig E/18) from the lid.
• Clean the filter with spirits or ethanol.
• Dry the filter with a soft cloth.
• Replace the filter in the filler opening
• Replace the lid on the filler opening.
Spark plug
• Remove the spark plug cable (fig G/13) from the spark plug (fig G/12).
• Remove the spark plug using the spark plug spanner (fig G/14).
• Clean the electrode (fig F/19) using a steel brush.
• Check the contract distance (correct value 0,7-0,8 mm) and adjust as necessary.
• Replace the spark plug.
Abb. G
Abb. D
Abb. E
11
