Mounting the Transmitter for console control operation
(1) Remove Transmitter from the plastic console-mounting bracket by slightly
bending the tab back to release transmitter from bracket.
(2) Place the transmitter in the desired location and orientation. Test systems by
operating the spotlight in all directions to verify you do not have interference
between the locations.
(3) The location for mounting the console bracket should be a smooth and flat
surface. Be sure you will have access to the underside of the chosen location,
and that you will be able to drill holes there without damaging existing wiring or
structures.
(4) Use the bracket as a template to mark mounting holes on the flat surface that is
convenient for operation of the light.
(5) It is recommended to use marine grade plywood as a back plate to strengthen the
installation.
(6) Drill the two 3/16 (4.5 mm)
holes through the mounting surface at the marked
points.
(7) Apply a small amount of non-silicone sealant (such as StarBrite #83801) to where
the screws penetrate the mounting surface.
(8) Fasten the bracket securely to the mounting surface using the two
6-32 x2”
(3.5mm x 50mm)
flat head stainless steel screws, flat washers, and locknuts
provided with the light. Do not over tighten.
Maintenance
Under normal conditions, mild detergent and water will be sufficient to keep the spotlight
clean. Avoid using caustic chemicals or abrasives as they may damage the housing.
No lubrication is necessary.
Battery Replacement
Only the wireless remote (R.F. Transmitter) requires a battery. Replace only with a 12
Volt Alkaline A23 battery. See section titled “Installing Transmitter Battery”.
