Hélicoptères Guimbal Maintenance Manual
CABRI G2 APPENDIX
Issue 03 Approved under DOA.EASA.21J.211 G-7
G-4 Safety pin table
Torques should be applied as specified in each assembly procedure.
Torques specified “dry” should be applied to a clean nut on a clean bolt.
For wet assemblies, use specified grease.
Cotter pins dimensions :
Safety pin
diameter length
Bolt diameter
mm
mm in mm in
5 1 0,04 10 0,4
6 1,6 0,06 10 0,4
8 1,6 0,06 15 0,6
10 2 0.08 20 0.8
