Guinaz GD0501 - Digital System AC Door Opener Diagram; Module Installation Guide

4 G503210 REV.0
2.3 ESQUEMA PARA SISTEMA DIGITAL CON ABREPUERTAS DE CORRIENTE ALTERNA.
DIAGRAM FOR DIGITAL SYSTEM WITH ALTERNATING CURRENT DOOR OPENER.
3 INSTALACIÓN DEL MÓDULO ACCESO CODIFICADO.
INSTALLATION OF THE CODED ACCESS MODULE.
1- Coloque la caja empotrable. 2- Afloje los dos tornillos inferiores hasta liberar el marco interior.
Place the flush-mounted box. Loosen the bottom two bolts to release the inner frame.
3- Separe el marco interior de la placa. 4- Sujete el marco interior a la caja empotrable mediante dos tornillos.
Separate the inner frame of the panel. Hold the inner frame to the flush-mounted box with two screws.
GUINAZ
REF: GD0501
MADE IN SPAIN
LED PROG
ON
A
1 S.
1
5 S.3 S.
212 1
7 S.
21
2
ON
B
ON
C
ON
D
1 2 3 4
+12
C
NO
-
1
2
3
4
MADE IN SPAIN
F1318
PRIM: 220V 50-60 Hz
SEC: 12V~1. 5 A (18 VA)
GUINAZ
PRIM.1 2
F1318
220Vac
1
2
Abrepuertas de corriente alterna (12Vac, 1A máx.)
Alternating current door opener (12Vac, max 1A)
Pulsador auxiliar
abrepuertas (opcional)
Auxiliary door opener
push-button (optional)
