G503210 REV.0 3
.
2. ESQUEMAS DE CONEXIÓN.
IMPORTANTE: El módulo acceso codificado es un dispositivo
independiente del resto de módulos que componen las
placas calle Guinaz. En ningún caso debe conectarse
mediante latiguillos a otros grupos de la placa calle.
2. CONNECTION DIAGRAMS.
IMPORTANT: The coded access module is a device which is
independent from the rest of the modules making up the
Guinaz street panels. Under no circumstance will they be
connected by means of cables to other street panel groups.
2.1 ESQUEMA PARA INSTALACIÓN INDEPENDIENTE.
DIAGRAM FOR STAND ALONE.
2.2 ESQUEMA PARA SISTEMA DIGITAL CON ABREPUERTAS DE CORRIENTE
CONTINUA.
DIAGRAM FOR DIGITAL SYSTEM WITH DIRECT CURRENT DOOR OPENER.
2
3
4
+
-
GUINAZ
REF: GD0501
MADE IN SPAIN
LED PROG
ON
A
1 S.
1
5 S.3 S.
2121
7 S.
21
2
ON
B
ON
C
ON
D
1 2 3 4
+12
C
NO
-
1
Pulsador auxiliar
abrepuertas (opcional)
Auxiliary door opener
push-button (optional)
Abrepuertas de corriente continua (12Vdc, 400mA máx.)
Direct current door opener (12Vdc, max 400mA)
GUINAZ
REF: GD0501
MADE IN SPAIN
LED PROG
ON
A
1 S.
1
5 S.3 S.
2
1
2
1
7 S.
2
1
2
ON
B
ON
C
ON
D
1 2 3 4
1
2
3
4
MADE IN SPAIN
F1318
PRIM: 220V 50-60 Hz
SEC: 12V~1.5 A (18 VA)
GUINAZ
PRIM.1 2
F1318
220Vac
1
2
Pulsador auxiliar
abrepuertas (opcional)
Auxiliary door opener
push-button (optional)
Abrepuertas de corriente alterna (12Vac, 1
A
máx.)
Alternating current door opener (12Vac, max 1A)
