Mixers - replaceable RA models
5. Commissioning
15
5 . 3 Connection to the container fitting
Use the following procedure to connect the fitting:
(see image 6)
- Check whether the container fitting (Pos. 9) is closed and if necessary close it.
- Release and remove the sealing cap of the fitting so that the fitting thread is free for connecting
the mixer.
- Put the mixer with retracted agitator shaft on the thread, screw the union nut on and pull the nut
tight using an appropriate key.
- Open the container fitting. The connected mixer will caulk.
- Push the agitator shaft completely through the hollow shaft to the connection side of the motor.
- Hold the motor shaft coupling tight with your left hand (Pos. 3.3).
- Rotate the agitator shaft coupling to the right with your right hand (Pos. 3.2) until the coupling
pin snaps into the notch.
- Put the mains plug into the socket.
- Switch the mixer on by turning the start/stop switch to the position "I".
5 . 4 Releasing the container fitting
Use the following procedure to release the container fitting:
(see image 6)
- Switch the mixer off by turning the start/stop switch to the position "0".
- Remove the mains plug.
- Hold the motor shaft coupling tight with your left hand (Pos. 3.3).
- Rotate the agitator shaft coupling to the left with your right hand (Pos. 3.2) and release the cou-
pling pin from the notch.
- Pull the agitator shaft (Pos. 3.1) completely back through the hollow shaft to the connection side
of the motor up to the stop.
- Close the container fitting.
- Unscrew the union nut using an appropriate key and remove the mixer.
6. Cleaning
Before cleaning, maintenance and repair work, the following switch-off procedure is to be main-
tained without fail:
- Ensure that the mixer is disconnected from the mains. (Switch off the start/stop switch and
remove the mains plug.)
- Close the product inlet. (Block the container fitting.)
- Disassemble the mixer.
 Daily cleaning (Quick cleaning)
Only clean using water between the individual working intervals. Do not use a cleaning agent as
this will require thorough rinsing.
 Complete cleaning
A complete cleaning procedure must be carried out every six months along with the container clean-
ing with the system at a standstill.
WARNING
• In case of non-compliance, this can endanger life and limb of the personnel!
