Guyson 2 - Monthly Procedures

Operation &
Maintenance
Manual
Issue:
10
A6ML0066 – Euroblast SF Instruction Manual
Date:
05/2019
Page: 56
7.3 Monthly
 Drain old media and discard (see section 7.3.1) and refill system with new media (see section
4.2).
7.3.1 Emptying media
To empty machine:
 Turn on the dust collector
 Turn on the cyclone
 Use an air line to clean inside cabinet
 Once clean leave dust extraction on for 10 minutes to clear pipes of residual media
 Switch off cyclone
 Switch off dust collector
 When motor has stopped remove pick-up tube from mixer box
 Place container under mixer box, unclip and remove mixer box and collect media
TAKE CARE TO AVOID TRAPPING FINGERS; THE MIXER BOX COULD BE
VERY HEAVY
