SFG-2000 Series User Manual
12
Lineup/Features
Series lineup
Features
Lineup
Duty
cycle
Offset TTL/
CMOS
Sweep AM/
FM
Counter
SFG-2004 (4MHz)
● ● ●
― ― ―
SFG-2007 (7MHz)
● ● ●
― ― ―
SFG-2010 (10MHz)
● ● ●
― ― ―
SFG-2020 (20MHz)
● ● ●
― ― ―
SFG-2104 (4MHz)
● ● ● ● ● ●
SFG-2107 (7MHz)
● ● ● ● ● ●
SFG-2110 (10MHz)
● ● ● ● ● ●
SFG-2120 (20MHz)
● ● ● ● ● ●
Main features
Performance
• High resolution using DDS and FPGA technology
• High frequency accuracy: 20ppm
• Low distortion: −55dBc
• High resolution 100mHz maintained at full range
Features
• Wide output frequency range: 4, 7, 10, 20MHz
• Various output waveforms: Sine, Square, and Triangle
• TTL/CMOS output
• Variable DC offset control
• Output overload protection
• Store/recall: 10 settings
• Counter up to 150MHz high frequency (SFG-2100
series)
• AM/FM with internal and external (SFG-2100 series)
• Sweep mode with LINE and LOG (SFG-2100 series)
Input/Output
Terminals
• Frequency output
• TTL/CMOS output
• Counter input (SFG-2100 series)
• External modulation input (SFG-2100 series)
