GWT PR 1713/00 - Page 46

Batching
PR1713 Operating manual
Seite 44
Inputs
on terminal
Outputs
on terminal
Slot 1
if the digital I/O-modul
PR1713/12 is plugged
in
Control signals
Start / Restart / quit B12
Stop B34
Abort B56
Go on B78
batch control
coarse valve A12
fine valve A34
discharge A56
error A78
Slot 2
if the digital I/O-modul
PR1713/12 is plugged
in
single signals
Start recipe 1 B12
Start recipe 2 B34
Start recipe 3 B56
Start recipe 4 B78
single signals
component 1 active A12
component 2 active A34
component 3 active A56
component 4 active A78
Slot 3
if the digital I/O-modul
PR1713/12 is plugged
in
single signals
Start recipe 5 B12
Start recipe 6 B34
Start recipe 7 B56
Start recipe 8 B78
single signals
component 5 active A12
component 6 active A34
component 7 active A56
component 8 active A78
2)
The Component output is
binary coded
and the recipe input is read
binary coded
.
The output addresses of the components had to be entered in the parameter SPM-out for each
component. The selection of the output is free.
For D1, D2, D5 and D8 components needs also the corresponding input addresses ('Quit' for
D1, D2 and 'Go on' for D5, D8)
Recipes could be started with the 'Start'-input. With the licence PR1713/21 for multiple recipes,
the recipe is started wich had been selected by one of the inputs of slot 2 or slot 3. Then the n-th
recipe from the alphabetic sorted list of recipes is taken.
Inputs
on terminal
Outputs
on terminal
Slot 1
if the digital I/O-modul
PR1713/12 is plugged
in
Control signals
Start / Restart / Quit B12
Stop B34
Abort B56
Go on B78
batch control
coarse valve A12
fine valve A34
discharge A56
error A78
Slot 2
if the digital I/O-modul
PR1713/12 is plugged
in
Start recipe binary coded
2
0
B12
2
1
B34
2
2
B56
2
3
B78
Component binary coded
2
0
A12
2
1
A34
2
2
A56
2
3
A78
Slot 3
if the digital I/O-modul
PR1713/12 is plugged
in
Start recipe binary coded
2
4
B12
2
5
B34
2
6
B56
2
7
B78
Component binary coded
2
4
A12
2
5
A34
2
6
A56
2
7
A78
