PR1713 Operating manual
Batching
Page 43
6.5 Address layout of signals
6.5.1 Digital in- and outputmodules PR1713/12.
Note: The functionality descibed here, is the PLC standard program. This program could be changed
with the software tool PR1750.
The output of the internal states or the input of 'commands' is defined by plugging the digital I/O cards
(PR13/12) in the slots. Depending on the inserted licences the PR1713 has two operating modes: the
indicator operation and the batch operating.
Indicator operation
Without a dosing licence PR1713/20 or PR1713/21
The indicator operation needs no further configuration.
Inputs
on terminal
Outputs
on terminal
Slot 1
if the digital I/O-modul
PR1713/12 is plugged
in
tare in B12
tare out B34
set to zero B56
weight valid B78
standstill A12
¼ d indication A34
tared A56
free A78
Slot 2
if the digital I/O-modul
PR1713/12 is plugged
in
Limit 1 on WP-A A12
Limit 2 on WP-A A34
Limit 1 on WP-B A56
Limit 2 on WP-B A78
Slot 3
Batching operation
For the batching operation the licence
PR1713/20
or
PR1713/21
has to be activated. With the digital
inputs the recipe could be controled: stop, restart, abort.
Depending on the configuration: 'Setup' and then 'Config' in the parameter: 'Comp.& recipe I/O:' two
variants exist: '
single
' or '
binary
'.
1)
For each Component a
single
output is set and for each recipe a
single
input is read.
The output addresses of the components had to be entered in the parameter SPM-out for each
component. The selection of the output is free.
For D1, D2, D5 and D8 components needs also the corresponding input addresses ('Quit' for
D1, D2 and 'Go on' for D5, D8)
Recipes could be started with the 'Start'-input. With the licence PR1713/21 for multiple recipes,
the recipe is started wich had been selected by one of the inputs of slot 2 or slot 3. Then the n-th
recipe from the alphabetic sorted list of recipes is taken.
