H3C S3600 Series Datasheet

SWITCHING
5
H3C S3600
Features
S3600
-
SI
S360
0
-
EI
Security
Security Features
l Support Centralized MAC address authentication
l Support Port isolation
l Support MAC address black hole
l Support MAC Address Learning Limit
l Prevent unauthorized access to the network by binding of MAC, IP and PORT
l Support SSH V2 (Secure Shell)
l Support Port security
l Support ARP detection
l Support IP source check
l Support EAD(endpoint admission defense)
l Support IEEE 802.1X user authentication
l Guest VLAN
l Support HWTACACS authentication
l Support HTTPS
Management/ Maintenance
Managementand
Maintenance
l Support CLI (Command Line Interface) ,console port ,Telnet configuration mode
l Support System configuration with SNMP v1/v2/v3
l Support HGMP V2
l Support RMON (Remote Monitoring) v1/v2/v3/v9 groups of MIBs
l Support H3C iMC , Web-based network management
l Detailed alarm/debug information output
l Support Ping, Tracert, HWping
l Support remote maintenance via Telnet Modems and SSH
l Support System log
l Hierarchical alarm management and alarm filtering
l Support DLDP (Device Link Detection Protocol)
l Support LLDP/LLDP-MED
l Saving debugging information into Flash
l Loopback detection on ports
l Support VCT (Virtual Cable Test)
Hardware configuration
Outline Dimensions
(HxWxD)mm
• S3600-28P-SI/ S3600-52P-SI/ S3600-28TP-SI/ S3600-28P-EI/ S3600-52P-EI/ S3600-28F-EI: 43.6*440*260 mm
• S3600-28P-PWR-SI/ S3600-52P-PWR-SI/ S3600-28P-PWR-EI/ S3600-52P-PWR-EI: 43.6*440*420 mm
Weight
• S3600-28P-SI/S3600-28TP-S/S3600-28P-EI/ S3600-28F-EI: 3.5kg
• S3600-52P-SI/ S3600-52P-EI: 4kg
• S3600-28P-PWR-SI/ S3600-28P-PWR-EI: 5.8kg
• S3600-52P-PWR-SI/ S3600-52P-PWR-EI: 6.2kg
Input Voltage
All S3600-EI series and S3600-28P-PWR-SI can be AC-powered and DC-powered (except S3600-28P-SI & S3600-52P-SI).
AC: 100v ~ 240V AC50/60Hz
DC: -48 ~ -60V DC
Maximum System Power
Consumption
40W (S3600-28P-SI/S3600-28P-EI/S3600-28TP-SI)
50W (S3600-52P-SI/S3600-52P-EI)
65W (S3600-28F-EI)
450W (S3600-28P-PWR-SI/ S3600-28P-PWR-EI, AC input)
Dissipated power: 150W
PoE: 300W
430W (S3600-28P-PWR-SI/ S3600-28P-PWR-EI, DC input)
Dissipated power: 60W
PoE: 370W
465W (S3600-52P-PWR-SI/ S3600-52P-PWR-EI, AC input)
Dissipated power: 165W
PoE: 300W
820W (S3600-52P-PWR-SI/ S3600-52P-PWR-EI, DC input)
Dissipated power: 80W
PoE: 740W
RPS(all EI series and S3600-28P-PWR-SI, S3600-52P-PWR-SI support)
MTBF
S3600-28P-SI: 57.1 years
S3600-52P-SI: 51.8 years
S3600-28P-EI: 45.9 years
S3600-52P-EI: 42.4 years
S3600-28P-PWR-SI/ S3600-28P-PWR-EI: 29.5 years
S3600-52P-PWR-SI/ S3600-52P-PWR-EI: 26.9 years
S3600-28TP-SI: 84.5 years
S3600-28F-EI: 51.9 years
Noise Parameter
S3600-28P-SI/EI : 40.1dBA
S3600-28TP-SI: 41.1dBA
S3600-52P-SI/EI: 46.5dBA
S3600-28F-EI: 51.3dBA
S3600-28P-PWR-SI/EI: 47.3dBA
S3600-52P-PWR-SI/EI: 46.3dBA
Environment
Operation temperature: 0°C ~ 45°C
Storage temperature: -40°C ~ 70°C
Operating humidity: 5% to 85% non-condensing
Relative humidity: 10% ~ 90%, non-condensing

H3C S3600 Series Specifications

General

Brand	H3C
Model	S3600 Series
Category	Switch
Language	English
