H3C S5130S Series User Manual

71
ﺮﻳﺬﺤﺗ:
ﺩﺮﻣ ﺭﺎﻴﺘﻟﺍ ﻲﺑﺮﻬﻜﻟﺍ – ﺍﺬﻫ ﺯﺎﻬﺠﻟﺍ ﺐﺳﺎﻨﻣ ﺓﺰﻬﺟﻷ ﺔﻗﺎﻄﻟﺍ TN. ﻼﻓ ﻦﻜﻤﻳ ﻩﺪﻳﻭﺰﺗ ﺔﻗﺎﻄﻟﺎﺑ ﻦﻋ ﻖﻳﺮﻃ ﻡﺎﻈﻧ ﺔﻗﺎﻃ IT. ﺍﺫﺇﻭ
ﺖﻧﺎﻛ ﺕﺍﺩﺭﻮﻣ ﺔﻗﺎﻄﻟﺍ ﻦﻣ ﻉﻮﻧ IT، ﺐﺠﻳ ﺪﻳﻭﺰﺗ ﻩﺬﻫ ﺓﺪﺣﻮﻟﺍ ﺪﻬﺠﺑ 230 ﺖﻟﻮﻗ (2P + T) ﺔﺒﺴﻨﺑ ﻝﺰﻋ ﻝﻮﺤﻤﻠﻟ 1:1 ﻊﻣ ﺔﻄﻘﻧ ﻝﺎﺼﺗﺍ
ﺔﻳﻮﻧﺎﺛ "ﺓﺪﻳﺎﺤﻣ" ﻢﺘﻳ ﺎﻬﻠﻴﺻﻮﺗ ﺓﺮﺷﺎﺒﻣ ﺽﺭﻷﺎﺑ (ﻲﺿﺭﻷﺍ).
ﺮﻳﺬﺤﺗ:
ﻝﺎﺧﺩﺇ ﺭﺎﻴﺘﻟﺍ ﺮﻤﺘﺴﻤﻟﺍ: ﺐﺠﻳ ﻪﻠﺼﻓ ﻦﻋ ﺭﺎﻴﺘﻟﺍ ﺮﻤﺘﺴﻤﻟﺍ ﻦﻋ ﻖﻳﺮﻃ ﻝﺰﻋ ﻱﻮﻗ ﻭﺃ ﺝﻭﺩﺰﻣ ﺎ ًﻘ ﻓ ﻭ ﺭﺎﻴﻌﻤﻠﻟ IEC 60950-1.
ﺮﻳﺬﺤﺗ:
ﺹﻮﺼﺨﺑ ﻝﺎﺧﺩﺇ ﺭﺎﻴﺘﻟﺍ ﺮﻤﺘﺴﻤﻟﺍ ﺪﻬﺠﺑ ﻦﻣﺁ ﺾﻔﺨﻨﻣ ﺔﻳﺎﻐﻠﻟ: ﺐﺠﻳ ﻥﺃ ﻖﻓﺍﻮﺘﻳ ﺭﺎﻴﺘﻟﺍ ﺮﻤﺘﺴﻤﻟﺍ ﻊﻣ ﺕﺎﺒﻠﻄﺘﻣ SELV (ﺪﻬﺠﻟﺍ
ﻦﻣﻵﺍ ﺾﻔﺨﻨﻤﻟﺍ ﺔﻳﺎﻐﻠﻟ) ﺎ ًﻘ ﻓ ﻭ ﺭﺎﻴﻌﻤﻠﻟ IEC 60950-1.
:ﻪﻴﺒﻨﺗ ﺯﺎﻬﺠﻟﺍ ﻖﺼﻠﻣ ﻊﻘﻳ ﻪﺗﺪﻋﺎﻘﻟ ﻲﺟﺭﺎﺨﻟﺍ ﺢﻄﺴﻟﺍ ﻰﻠﻋ ﻞﻘﻨﻠﻟ ﻞﺑﺎﻘﻟﺍ.
ﺮﻳﺬﺤﺗ
: ﻞﺒﻗ ﻞﻴﺻﻮﺗ ﻞﺒﻛ ﺭﺎﻴﺗ ﺩﺩﺮﺘﻣ ﻭﺃ ﻪﻠﻀﻓ ﻦﻣ ،ﺓﺪﺣﻮﻟﺍ ﺐﺠﻳ ﻑﺎﻘﻳﺇ ﻞﻴﻐﺸﺗ ﺭﺪﺼﻣ ﺭﺎﻴﺘﻟﺍ ﺩﺩﺮﺘﻤﻟﺍ ﻱﺬﻟﺍ ﺩﻭﺰﻳ ﺍﺬﻫ ﻞﺒﻜﻟﺍ.
ﻪﻴﺒﻨﺗ:
ﻥﺎﻤﻀﻟ ﺖﻴﺒﺜﺗ ﺯﺎﻬﺠﻟﺍ ﻰﻠﻋ ﻂﺋﺎﺤﻟﺍ ،ﻡﺎﻜﺣﺈﺑ ﻰ ﺟ ﺮ ُﻳ ﻡﺍﺪﺨﺘﺳﺍ ﺭﺎﻤﺴﻣ ﻅﻭﻭﻼﻗ ﺮﻄﻘﺑ 4.2 ﻢﻣ ﻰﻠﻋ ﻞﻗﻷﺍ ﺚﻴﺤﺑ ﻎﻠﺒﻳ ﺮﻄﻗ ﺱﺃﺭ
ﺭﺎﻤﺴﻤﻟﺍ 8 ﻢﻣ ﻰﻠﻋ ﻞﻗﻷﺍ.
ﺮﻳﺬﺤﺗ:
ﺪﻨﻋ ﺖﻴﺒﺜﺗ ﺞﺘﻨﻤﻟﺍ ﻰﻠﻋ ،ﻂﺋﺎﺤﻟﺍ ﺐﺠﻳ ﻚﻴﻠﻋ ﻡﺍﺪﺨﺘﺳﺍ ﺖﺒﺜﻣ ﻢﺋﻼﻣ
ﺮﻳﺬﺤﺗ:
ﺪﻨﻋ ﺖﻴﺒﺜﺗ ﺞﺘﻨﻤﻟﺍ ﻰﻠﻋ ،ﻂﺋﺎﺤﻟﺍ ﻻ ﻪﺘﺒﺜﺗ ﻲﻓ ﻊﺿﻭ ﻥﻮﻜﺗ ﻪﻴﻓ ﺕﺎﺤﺘﻓ ﺔﻳﻮﻬﺘﻟﺍ ﻰﻠﻋﻷ ﻭﺃ ﻞﻔﺳﻷ.
ﺮﻳﺬﺤﺗ:
ﺪﻨﻋ ءﺍﺮﺟﺇ ،ﺕﻼﻴﺻﻮﺘﻟﺍ ﺹﺮﺣﺍ ﻰﻠﻋ ﻡﺪﻋ ﻊﻓﺩ ﺞﺘﻨﻤﻟﺍ ﻰﻠﻋﺃ ﻂﺋﺎﺤﻟﺍ ﻭﺃ ﺍًﺪﻴﻌﺑ ﻪﻨﻋ.
ﺮﻳﺬﺤﺗ:
ﺐﺠﻳ ﻞﻴﺻﻮﺗ ﺓﺪﺣﻮﻟﺍ ﻞﻜﺸﺑ ﻢﺋﺍﺩ ﻲﺿﺭﺄﺑ ﻝﻭﺰﻌﻣ ﻞﺒﻗ ﺎﻬﻠﻴﻐﺸﺗ. ﺐﺠﻳ ﻥﺃ ﻥﻮﻜﺗ ﺔﻘﻄﻨﻤﻟﺍ ﺔﺿﺮﻌﺘﺴﻤﻟﺍ ﻞﺻﻮﻤﻠﻟ ﻲﺿﺭﻷﺍ
ﻝﻭﺰﻌﻤﻟﺍ ﻰﻠﻋ ﻮﺤﻨﻟﺍ ﺩﺪﺤﻤﻟﺍ ﻲﻓ ﻝﻭﺪﺠﻟﺍ ﻲﻟﺎﺘﻟﺍ
ﺯﺍﺮﻃ ﺯﺎﻬﺠﻟﺍ
ﺪﺤﻟﺍ ﻰﺼﻗﻷﺍ ﺔﻘﻄﻨﻤﻠﻟ ﺔﺿﺮﻌﺘﺴﻤﻟﺍ
ﻢﻣ
2
AWG
H3C S5130S-52P-EI,
H3C S5130S-52S-EI,
H3C S5130S-28P-EI,
H3C S5130S-28S-EI,
H3C S5130S-28S-HI,
H3C S5130S-52S-HI,
H3C S5130S-52F-EI,
H3C S5130S-20P-EI,
H3C S5130S-28S-LI ,
H3C S5130S-52S-LI,
H3C S5130S-28S-SI,
H3C S5130S-52S-SI,
H3C S5130S-28P-EI-M,
H3C S5130S-52P-EI-M,
H3C S5130S-28S-EI-M,
H3C S5130S-52S-EI-M,
H3C S5130S-12TP-EI,
H3C S5130S-10P-EI,
H3C S5130S-28S-PWR-EI,
H3C S5130S-28P-PWR-EI,
H3C S5130S-12TP-HPWR-EI,
H3C S5130S-10P-HPWR-EI,
H3C S5130S-20P-PWR-EI
H3C S5130S-28TP-EI,
H3C S5130S-52TP-EI,
H3C S5130S-28F-EI,
0.75 18

H3C S5130S Series Specifications

General

Category	Switch
Managed	Yes
Packet Buffer	Varies by model
Power Consumption	Varies by model
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Relative Humidity	5% to 95% (non-condensing)
Weight	Varies by model
Series	S5130S Series
Ports	Varies by model
Uplink Ports	Varies by model
Stacking	Supported
Layer	Layer 2/3
Power Supply	AC or DC
Dimensions	Varies by model
MAC Address Table	16K
Forwarding Rate	Varies by model (e.g., up to 96 Mpps)
