BloodTrack Kiosk® V5 Installation Guide
HAE: SM-BloodTrack-08(AA) SBC100xxx
GBE: 2000-JNB0012 5
The BloodTrack Kiosk V5 met the following test requirements as called for in those
standards.
Type
Port
Test Applied
Levels/Frequency Range
EMISSIO
NS
240 VAC /
110 VAC
Enclosure
Radiated Emissions
30 MHz to 6 GHz (EU & FCC)
1 x AC Port
Conducted Emissions
150 kHz to 30 MHz
Harmonics & flicker (EU only)
Refer to Standard
IMMUNITY
Enclosure
Electrostatic discharge
4 kV Contact, 8 kV Air
Radiated RF Immunity
10 V/m; 80 MHz to 1 GHz
10 V/m; 1.4 to 2.0 GHz
1 V/m; 2.0 to 2.7 GHz
1 x AC Power
Conducted RF Immunity
10 Vrms; 150 kHz to 80 MHz
Fast transient bursts
2 kV
Surges
L-L; 1 kV, L-E 2 kV
Voltage dips and interruptions
>95%, 0.5 cyc; 30%, 25 cyc;
0%, 1 cyc, 705, 25 cyc,
70%, 30 cyc & 0%, 250 cyc
1 x Signal
Conducted
RF Immunity
10 V/m; 150 kHz to 80 MHz
Fast transient bursts
1 kV
2.3 Physical Specifications
The approximate dimensions and weight of the BloodTrack Kiosk V5 are:
Component
Specifications
Height
11.4 in. 290 mm
Width
12.4 in. 315 mm
Depth
7.6 in. 193 mm
Weight of BloodTrack Kiosk V5 with shelf
10.8 lbs. 4.9 kg
Height BloodTrack Kiosk V5 with shelf
19.2 in. 480 mm
Height of BloodTrack Kiosk V5 with adjustable desk stand
18.3 in. (max) 465 mm
Width of stand
16.7 in. 424 mm
Depth of stand
9.8 in. 250 mm
Weight of stand
10.6 lbs. 4.8 kg
Maximum loading on optional smart shelf
3.3 lbs. 1.5 kg
