hager EMN005 User Manual

Staircase Time Lag Switches
Market Reference EAN-Code Description
EMN001 3250612339969 Staircase time lag switch
EMN005 3250612339952 Multifunction staircase time lag switch
Technical Data
Mains supply
230VAV(+10%/-15%)
50Hz / 60Hz
Contact µ16A - 250V AC1
Consumption < 5VA / <1W
Size(mm) 83 x 60 x17.5
IngressProtection IP20
Load Type
Incandescent/Halogen230V 2300 W
Halogen VLV associated with
ferromagnetic transformer
1500 W
Fluorescent lamps / with
ferromagnetic transformer
100 VA / 100 µF
Fluorescent lamps Mono / Duo 1044 W
Fluo Compact with electronic
integratedtransformer(E27)20W
460 W
Technical Characteristics
Functional Characteristics
Time Delay
30 seconds
to 10 minutes
30 seconds
to 10 minutes
/1 hour by
pressing the
push button
for more than
3 seconds
Retrigger Yes
Local Command Automatic / Override ON
Max. current in rest position 100 mA
Automatic 3/4 recognition Yes
Working temperature -10ºC to +50ºC
Storage temperature -25ºC to +70ºC
Standards
EN 60669-1, EN 60669-2-1,
EN 60669-2-3, EN 6069-2-1
EMN001 EMN005EMN001 EMN005
15/01/092/2
