Page #13 background imageLoading...
Page #13 background image
23
Configuration or programming phase
Num.
What to do if...
18
The limits of
installation are
reached.
Solutions
19
On starting, your
tool displays the
screen 'Menu'.
5
20
The memory card
of the site is lost.
22
Configuration or programming phase
Num. What to do if...
16
A product is in
capacity over-
range (number of
links).
Solutions
17
The limits of the
media coupler are
reached.
5
- Check in the list '' product information '' (see §3 page 19 of TX100 Instructions) the
products preceded by: !
- Select the concerned product using the key .
- Check if the overrange of the number of links in the menu '' product information
(see §3 page 19 of TX100 Instructions).
Note: if the number of links is exceeded a checkmark
symbol appears on the line '' Links ''.
In this case, perform installation link configuration /and or output wiring opti-
mising.
- The message '' coupler overrange capacity " appears on TX100 screen.
- The media coupler makes it possible to manage up to 62 communications radio = >
wire.
The number of communications per product is as follows:
- TU204A : 2 - TU208A : 3 - TU224A : 9
- TR302A : 1 - TR304A : 2 - TR302B : 1
- TR304B : 2 - TR501 : 1 - TR521 : 2
- The media coupler makes it possible, to manage up to 50 addresses of group wire
= > radio. These group addresses are visible in mode '' Expert ''.
The messages '' coupler overrange capacity "(see note No.17)," input number over-
range ' appear on TX100 screen.
Note: See § '' System Limits of page 2 of TX100 Instructions.
There is no memory board in the product.
Note: The displayed functions are accessible without memory board.
- Configure an installation, extinguish the tool, to insert a memory board and to start
again
This card is essential to modify the configuration of installation.
- If this card is no longer available all products must be set back into factory mode
and a new configuration must be performed.
The switch-over to factory mode can only be made by the unit “Outside of installa-
tion": (see §1 page 18 of TX100 Instructions).
Note: To save reconfiguration due to loss of memory card, be sure to
make a copy of the card. See Instructions §8 page 22.
