Configuration or programming phase
Num.
How to...
13
To link a wire input
state indication
to another
wire unput.
Solutions
2
10
Configuration or programming phase
Num. How to...
12
To link a main dim-
mer switch to one
or more dimmer
slave switches.
Solutions
2
- Identify the dimmer switch intended to operate as a Master and carry out a unit
factory return (see E17 page 18 of User’s Instructions TX100).
- Set the configurer in mode 'prog'.
- Guve the key a long press to start the automatic search of outputs.
- Select the filter "+ Info" (see note §3.2 page 11 of User’s Instructions TX100).
Note: The special functions ( and ) are at the end of the
list: their numbers start with 512 andare decremented.
- Note the dialing of special channels of main dimmer switch.
- Give the key again a long press by connecting the other dimmer switches, if
necessary.
- Carry out a link between the input of the main dimmer switch and outputs
of all slave dimmer switches.
- Validate by a long press of key .
- Return to mode “auto”.
- Select the Expert mode (see §18 page 27 of User’s Instructions TX100).
- Set TX100 in mode '' Prog''.
- Select the desired indication input and the output to be linked.
- Enter the expert mode by pressing the centre screen key: the list of objects is
displayed e.g. link between an indication input of state ON/OFF of TX206C and
output of TX204A.
- Select object "ION/OFF" from the list dedicated to inputs using the keys .
- Assign a group address to it or retain it if if a group address is already associated.
- Switch to the list of the functions dedicated to outputs by pressing the key .
- Select object "ON/OFF" of output from the list dedicated to outputs using the keys
.
- Assign the same group address to it (new or existing).
- Validate the expert link by giving the key a long press.
- Return to mode "auto" .
