FR
2 Viper TTL - Français
Nomenclature Viper TTL
08
06
05
04
A B C
07
09
01
03
02
15 14 13 11
16
10
12
Transmetteur
(A) Groupe A
(B) Groupe B
(C) Groupe C
(1) Interrupteur ON/OFF
(2) SEL : bouton de sélection
(3) Molette de réglage : pour
ajusterlesparamètres
(4) Bague de verrouillage
(5) Ecran LCD
(6) Indicateur LED (Marche/
Arrêt, statut)
(7) Sabot
(8) Bouton de test
(9) Port Micro USB (pour
miseàjourlogiciel)
Récepteur
(10)Griffeporte-ash
(11)LEDdestatut(allumé/éteint)
(12) Bouton ON/OFF
(13) Port Micro USB
(14) Prise pour câble
(15) Bouton Test
(16) Interrupteur Groupe
A/B/C
