Haier 39 Series User Manual

EN
2-Product description
7
Note:
-
2.1 Picture of appliance
1. Detergent / Softener drawer
2. Programme selector
3. Worktop
4. Display
5. Rating plate
6.
7. Adjustable feet
1. Transportation bolts (T1-T4)
2. Back cover
3. Back cover screws (S1-S6)
4. Power cord
5. Water inlet valve
6. Drain hose
2.2 Accessories
Check the accessories and literature in occordance with this list (Fig.: 2-3).
Inlet hose-
assembly
5 Blanking
plugs
Drain hose
bracket
Warranty
card
2-3
1400
rpm Capacity
7kg
+++
A
Energy
Speed up
HW70-BP1439
Temp.
Speed Start/pauseExtra rinse DelaySteam
Cotton
Synthetics
Mix
Sportwear
Jeans
Baby clothes
Cotton+
Hygienic
Fast wash
Spin
Bedding
Handwash
Delicate
Daily Wash
Quick 15”
Wool
2 3
5
6
7
41
T1
T2
T3
S1
S2
S6
S4
T4
1
2 3 4 5 6
S3
S5
Noise red-
uction pads
