-6-
When attaching the wall mount screws into the back of the TV, use the maximum torque of 8
kilogram force centimeter. The length of the wall-mount screws vary depending on the
wall-mount bracket you purchased. The recommended wall mount screw is M6 with an
approximate length of 8mm. Please see the instructions that came with the wall-mount bracket
for screw lengths.
Please follow the instructions of the user manual that came with the wall mount bracket to
install and please do not use excessive torque when attaching the wall mount screw to the TV.
Warning: the angle between the TV and wall must not be greater than 3 degrees.
WALL MOUNT INSTALLATION INSTRUCTIONS
wall
Note: wall mount bracket and screws are not included.
200mm
400mm
To Next Page
