(B) Denition and description of SW03

Note *:

• Set the address by code when connecting the centralized controller or gateway or charge system.

• Address of centralized controller=communication address+0 or+64.

SW03_ 2=OFF, address of centralized controller=communication address+0=communication address

SW03_ 2=ON, address of centralized controller=communication address+64 (applies when centralized controller is

used and there are more than 64 indoor units)

• To use with 0010451181A in use, it is required to use code for address setting. Set SW03_1=0N

and SW03_ 2=OFF; SW03_3, SW03_ 4, SW03_5, SW03_6, SW03_7 and SW03_ 8 are address codes which are set

according to actual address.

• Address setting function of wired controller for ultrathin card machine is disnabled.

SW03_1

Manner of set

address

0 Set the address with wired controller or automatism (default)

1 Set the address with dip switch

SW03_2

SW03_8

Set the

Communication

and Central

control address

with dip switch

(*Note)

[2] [3] [4] [5] [6] [7] [8] Address of indoor unit

Address of centralized

controller

0 0 0 0 0 0 0 0# (Default) 0# (Default)

0 0 0 0 0 0 1 1# 1#

0 0 0 0 0 1 0 2# 2#

… … … … … … … … …

0 1 1 1 1 1 1 63# 63#

1 0 0 0 0 0 0 0# 64#

1 0 0 0 0 0 1 1# 65#

1 0 0 0 0 1 0 2# 66#

… … … … … … … … …

1 1 1 1 1 1 1 63# 127#
