Haier AD28NAMBEA - Exploded Views: AP242 ACBEA Indoor Unit; AP242 ACBEA Indoor Unit Parts List

No. Spare parts number Spare parts description in english Qty. Model
Failure
rate
the proportion of the
spare-part stock Remark
1 001A1231233 Inlet grill 1 AP242ACBEA 0.00% 0.000% ×
2 001A1301502 Inlet grill insert 2 AP242ACBEA 0.00% 0.000% ×
3 001A1231234 Front panel 1 AP242ACBEA 0.00% 0.000% ×
4 0010450638 Operation panel 1 AP242ACBEA 0.00% 0.000% ×
5 001A1432687 Horizontal blade 6 AP242ACBEA 0.00% 0.000% ×
6 001A1734970 Vertical air outlet pad 2 AP242ACBEA 0.00% 0.000% ×
7 001A0100357 Vertical blade 1 AP242ACBEA 0.00% 0.000% ×
8 001A1734832 Air damper pad 1 AP242ACBEA 0.00% 0.000% ×
9 001A1301508 Air damper 1 AP242ACBEA 0.00% 0.000% ×
10 001A0400118 Heat exchanger assembly 1 AP242ACBEA 0.01% 0.012%
11 001A1301440 Evaporator left mounting plate 1 AP242ACBEA 0.00% 0.000% ×
12 001A1301441 Evaporator right mounting plate 1 AP242ACBEA 0.00% 0.000% ×
13 0010150192 Left board 1 AP242ACBEA 0.00% 0.000% ×
14 001A17341250 Left board pad 1 AP242ACBEA 0.00% 0.000% ×
15 001A1231237 Top cover plate 1 AP242ACBEA 0.00% 0.000% ×
16 001A1742836 Cover 1 AP242ACBEA 0.00% 0.000% ×
17 001A1734023 Side board horizontal pad 1 AP242ACBEA 0.00% 0.000% ×
18 0010150193 Right board 1 AP242ACBEA 0.00% 0.000% ×
19 001A0100828 Back guard 1 AP242ACBEA 0.00% 0.000% ×
20 001A1101145 Wiring plate 1 AP242ACBEA 0.00% 0.000% ×
21 001A1734842 Thermal insulation pipe 1 AP242ACBEA 0.00% 0.000% ×
22 001A5002078 Special nut 1 AP242ACBEA 0.00% 0.000% ×
23 001A0100575 Bottom plate 1 AP242ACBEA 0.00% 0.000% ×
24 001A1745106 Plastic cushion 1 AP242ACBEA 0.00% 0.000% ×
25 0010402372 Motor 1 AP242ACBEA 0.02% 0.024% *
26 001A5739020 Mounting wiring clamp 1 AP242ACBEA 0.00% 0.000% ×
27 001A1101146 Pipe press plate 1 AP242ACBEA 0.00% 0.000% ×
28 001A1752911 Cushion rubber 1 AP242ACBEA 0.00% 0.000% ×
29 001A1452695 Cushion rubber 1 AP242ACBEA 0.00% 0.000% ×
30 0010250163 Drain pan 1 AP242ACBEA 0.00% 0.000% ×
31 001A1452695 Fan pad 1 AP242ACBEA 0.00% 0.000% ×
32 001A5102050 Nut 1 AP242ACBEA 0.00% 0.000% ×
33 001A2300062 Centrifugal fan 1 AP242ACBEA 0.02% 0.024% *
34 001A1742931 Down shell press plate cushion 1 AP242ACBEA 0.00% 0.000% ×
35 001A1301445 Down shell press plate 1 AP242ACBEA 0.00% 0.000% ×
36 001A1431647 Wiring clamp (plasticizing) 1 AP242ACBEA 0.00% 0.000% ×
001A1301437 Reinforcing plate (left) 1 AP242ACBEA 0.00% 0.000% ×
001A1301438 Reinforcing plate (right) 1 AP242ACBEA 0.00% 0.000% ×
38 0010200026 Air ring 1 AP242ACBEA 0.00% 0.000% ×
39 001A0100385 Down shell 1 AP242ACBEA 0.00% 0.000% ×
40 001A2400102 Filter 1 AP242ACBEA 0.00% 0.000% ×
41 001A0100075 Lock 1 AP242ACBEA 0.00% 0.000% ×
42 001A1734967 Sealing plate 1 AP242ACBEA 0.00% 0.000% ×
43 001A17621241 Sealing plate 1 AP242ACBEA 0.00% 0.000% ×
44 001A1757833 Cushion rubber 1 AP242ACBEA 0.00% 0.000% ×
45 001A3000236 Synchro-motor 1 AP242ACBEA 0.02% 0.024% *
46 001A1301448 Electric box cover 1 AP242ACBEA 0.00% 0.000% ×
47 0010250201 Wire clamp 1 AP242ACBEA 0.00% 0.000% ×
48 001A4000151 Terminal block 1 AP242ACBEA 0.00% 0.000% ×
49 0010450450 Transformer 1 AP242ACBEA 0.01% 0.012%
50 001A3600018 Fan capacitor 1 AP242ACBEA 0.04% 0.048% *
51 001A1452695 Cushion rubber 1 AP242ACBEA 0.00% 0.000% ×
52 0010400911 Indoor PCB 1 AP242ACBEA 0.02% 0.024% *
53 / / AP242ACBEA
54 001A13011074 Electric box 1 AP242ACBEA 0.00% 0.000% ×
55 001A1301444 Fixing horizontal plate 1 AP242ACBEA 0.00% 0.000% ×
56 001A1734967 Sealing cushion 1 AP242ACBEA 0.00% 0.000% ×
57 001A1752840 Supporting pad 1 AP242ACBEA 0.00% 0.000% ×
58 001A3800128 Pipe temp. sensor 1 AP242ACBEA 0.00% 0.000% ×
59 001A0100407 Supporting plate assembly 1 AP242ACBEA 0.00% 0.000% ×
Parts list
37
