Connector Wiring diagrams
Domestic air conditioner
6. Printed Circuit Board Connector Wiring Diagram
PCB (1) (Indoor control PCB)
Note: Other designations
1) SW1 Connector for Emergency operation ON / OFF switch
2) SW2 1 Select remote code A or B,
2 Select room card able or disable⩖
3,4 Select eeprom code 23ʙ26ʙ33 and 35 ,
3) RV1 Varistor
4) FUSE1 Fuse 3.15A/250VAC
Series PCB connector Connect with load
1 CN21
Connector for power N and L
2 CN52
3 CN27 Connector for ground
4 CN23
Connector for communication between indoor and outdoor
unit
5 CN6 Connector for thermistors
6 CN9 Connector for fan motor
7 CN7 Connector for display
8 CN5 Connector for up-down stepmotor
9 CN11 Connector for left-right stepmotor
10 CN2 Connector for wiring-control
11 CN51 Connector for room card
12 CN34 Connector for wifi-control
13 CN1 Reserved connector
13
To Next Page
