Notice: MyZone drawer
▶ One of the three functions of the MyZone compartment must always be activated
▶ When you chose “0°C Fresh“ or “Cheese” set the temperature of the refrigerating
compartment in the middle level (5°C), in order to preserve your food in the optimal
storage environment.
Notice: Panel lock
The control panel of MyZone and HumidityZone drawer is automatically blocked
against activation if door is open. For any settings the control panel must be unlocked.
5.11.4 Select function for MyZone drawer
The function can be selected by using the separate pa-
nel (Fig. 5.11.4-1) which is located at the drawer cover.
1. If indicator “n” illuminates the panel is locked and
must be unlocked by touching key “N” (3 Sec. Lock)
for 3 seconds (Fig. 5.11.4-2). A buzzer sounds and
2. Touch corresponding key “K/L/M” of desired func-
tion. After a few seconds corresponding indicator
“k/l/m” illuminates .and the function is activated.
3. Lock the panel by touching key “N” (3Sec. Lock) for
3 seconds. A buzzer sounds and indicator “n” turns
on (Fig. 5.11.4-3).
Cheese Fruits & Veg 0°C Fresh 3Sec. Lock
K N
M
5.11.4-1
3Sec. Lock
3Sec. Lock
5.11.4-2 5.11.4-3
5.12 HumidityZone drawer
The fridge compartment is equipped with a HumidityZone drawer. Appropriate de-poly-
thene module enhance the freshness preservation by removing the ripener.
Following functions are available:
5.12.1 Select function for HumidityZone drawer
The humidity in this drawer can be adjusted by using
the separate humidity control panel (Fig. 5.12.1) which
is located at the drawer cover.
The steps are the same as describe in chapter 5.11.4
but only by using the panel for HumidityZone.
High Hum.Low Hum. Mid Hum. 3Sec. Lock
G J
5.12.1
Function Recommended food
Low Hum.
Dry fruit and other dry food with low water content like like butter, fats
and oils, bread or chocolate.
Mid Hum.
Pears, grapes cherries etc.
High Hum.
Cabbage, mushrooms etc.
L
H I
21
EN
Use
