FlexFit Pro
2. Specications
Model Name
System AL24LP
Outdoor 1U24LP2VHA
Indoor AL24LP2VH*
Cooling
Rated Capacity Btu/hr 24000
Capacity Range Btu/hr 6800-27000
Rated Power Input W 2,087
SEER 17
EER 11.5
Moisture Removal Pt./h 5.1
Heating
Rate Heating Capacity 47°F Btu/hr 27300
Heating Capacity Range Btu/hr 6800-30500
Rated Power Input W 2,281
HSPF 10
Operating Range
Cooling °F(°C) 0~115F(-18-46C)*
Heating °F(°C) -4°F~75°F
（
-20-24
℃）
Power Supply Voltage, Cycle, Phase V/Hz/- 208-230/60/1
Outdoor Unit
Compressor Type DC Inverter Driven Rotary
Maximum Fuse Size A 25.0
Minimum Circuit Amp A 21.0
Outdoor Fan Speed RPM 750/700/650/600/500/400/300
Outdoor Noise Level dB 47
Dimension: Height in (mm) 38 (965)
Dimension: Width in (mm) 37 3/8(950)
Dimension: Depth in (mm) 14 5/8(370)
Weight (Ship/Net)- lbs (kg) 202.8/ 176.4 (92/80)
Indoor Unit
Fan Speed Stages 4 + Auto
Airow (Turbo/High/Med/Low/Quiet) CFM 740/630/480/400
Motor Speed (Turbo/High/Med/Low/Quiet) RPM 500/400/300/250
Indoor Sound Level dB (Turbo/High/Med/Low/Quiet) 36/33/29/26
Dimension: Height in (mm) 9 5/8 (246)
Dimension: Width in (mm) 33 1/8(840)
Dimension: Depth in (mm) 33 1/8(840)
Max. External Static Pressure in.W.G(Pa) NA
Drainpipe Size O.D. in 1 1/4
Internal Condensate Pump Standard
Max. Drain-Lift height in(mm) 39 3/8 (1000)
Grill Model PB-950KB
Grill Dimension: Height in (mm) 2 (50)
Grill Dimension: Width in (mm) 37 3/8 (950)
Grill Dimension: Depth in (mm) 37 3/8 (950)
Weight (Ship/Net)- lbs (kg) 79.4/68.3 (36/31)
Refrigerant Lines
Connections Flare
Liquid O.D. in 3/8
Suction O.D. in 5/8
Factory Charge Oz 88.2
Maximum Line Length Ft / m 165/50
Maximum Height Ft / m 100/30
