Eleven . Error Presentation Mode
11.1 Three Indicator Error Code
Error Display
Error Conditions
PS Timer Operation
Operation Heating Cooling
Indoor
Outdoor
Automatic
Reset
Cause
Indoor Senistor Error ƾƵƵ * * 1. Connector loose contact or ambient
temperature sensor error.
Indoor Heat Exchange
Senistor Error
ƾƶƶ * * 1. Connector loose contact or coil sensor
error.
Outdoor Senistor Error ƶƾƵ * * 1. Connector loose contact or sensor error
*
1. There is large interference source around
or wiring error. Transmission Error ƵƵƾ
* 2. Wiring error or control panel error.
* 1. Whether control panel is damaged. EEPROM Error ƾƶƾ
* 1. Whether control panel is damaged.
Indoor Fan Error Ƶƶƾ *
Note ƶOnƾBlinkƵOff * This
function is
available.
Twelve . Emergency Switch
When shutdown, press emergency switch down for less than 5s, the unit will start emergency operation.
When shutdown, press emergency switch down for more than 5s but less than 10s, the unit will start trial
operation.
When shutdown, press emergency switch down for more than 10s but less than 15s, it will demonstrate
the previous error.
When shutdown, press emergency switch down, the panel will display automatic operation.
When shutdown, press emergency switch down for less than 15s, or remove hand from emergency
switch, the unit will not accept remote control signal.
Unit enters shutdown condition after 15s.
Unit can receive remote control signal after 15s.
Press emergency switch during operation, air-conditioner will shut down.,
During operation, if error occurs, press emergency switch to shut down the unit to clear error condition.
During error presentation, press emergency switch and error presentation will end.
During operation, if emergency switch is pressed continuously (press and hold) in normal or abnormal
condition (such as tact switch short circuit) or in error presentation condition, the unit can also receive
remote control signal.
Error Record Presentation Mode:
When press and hold switch for 10s it gives out 3 sounds, release switch to enter error record
presentation mode. Press and hold switch for 15s, panel display is off and error record presentation
mode is cancelled.
Previous alarm information will be sent to display panel for status display.
Error record presentation mode is cleared after 10s. (Error record presentation mode is only displayed
for 10s.)
During the presentation, no remote control signal except shutdown signal is accepted.
There is no presentation when no error occurs, only buzzer utters sound.
